RAMP LOCATIONS
Item Part Number
Part Number
1.
A-16059
Cross-Over Chute Assy.
2.
A-16164
Lock-Up Ramp Assembly
3.
A-16056
Right Chute Assembly
4.
A-16062
Center Ramp & Opto's Assy.
a)
03-8506
Opto Mtg. Base - Black
b)
03-8506-1
Opto Mtg. Base - White
5.
A-16174
Shooter Ramp Assembly
6.
A-16133
Main Chute Ass. (Under plfd.)
a)
5647-12693-13 Miniature Switch ( 3 used)
b)
A-16535
Ramp Prox Opto Sensor PCB
7.
A-16060
Main Ramp Assembly
a)
5647-12693-21 Miniature Switch
b)
A-13627-2
Switch Gate Assembly
8.
12-7104
Mini-Feed Wire Chute
9.
A-16058
Mini-Inside Wire Chute Assy.
10.
03-8826
Small Chute Assy. (Under plfd.)
o
Twilight Zone 2-57
