PINBALL GAME ASSEMBLY INSTRUCTIONS
•
TWILIGHT ZONE IS A 6 BALL GAME.
Power:
Domestic 120V
@
60 Hz
Dimensions:
Width: 29" Approx.
Foreign 230V
@
50 Hz
Depth: 55" Approx.
Japan 100V
@
50Hz
Height: 76" Approx.
Isms:
32
0
F to 100
0
F
(0
0
C to 38
0
C)
Humiditr.:
Not to exceed 95% relative.
Weight:
Approx. 322 Ibs. (crated)
1. Remove all cartons, parts, and miscellaneous ~emsfrom the shipping container and set them aside.
2. Place the cabinet on a support and attach rear legs using leg bolts. Leg levelers and leg bolts are
provided among the parts in the cash box.
3. Attach the front legs (after installing leg levelers), using leg bolts. See diagram below.
-
,
-
....
,
I
, ,
..•..
"\
,
I..........
\
,J......
.....,
,
..•....•..
,
.•...•..
<
rf- -....---- - -
1
Detail View·
La; Leveler
_\~/....
I
r-::--"__~-:..:-- - - - - _
J
"
"
\
See Oetaa
Vi1M' 1
•
\
I
,
,
'-'
4. Reach into the cabinet and backbox and ensure that the interconnecting cables are not kinked or
pinched. Be careful to avoid damaging wires at any stage of the assembly process.
5. Raise the hinged backbox upright and latch ~ into position. Unlock the backbox, and remove the
backglass, storing it carefully to avoid scratches. Remove the shipping block holding the Insert
Board. Unlatch and open the Insert Board. Carefully lift the Speaker Panel and lay it down on the
playfield glass. Be careful not to damage the Dot Matrix Display/Driver Board. This allows access to
the bolt holes used for securing the backbox upright. Install the washer-head mounting bolts
through the bottom holes of the backbox into the threaded fasteners in the cabinet to secure the
backbox. Close the Insert Board and latch it in position. Replace the Speaker Panel. Reinstall the
backgJass,and Jockthe backbox.
&
CAUTION
FAILURE
TO
INSTALL
the backbox mounting hardware properly can cause personal injury.
NEVER TRANSPORT
a pinball game with the hinged backbox erect. Always lower the backbox
forward onto the playfield cabinet on a layer of protective material to prevent marring or damage and
possible personal injury.
Twilight Zone 1-2
