Manual
Operations:
The manual operations are selected by using the
"+"
and "-" coin door buttons. The name of
the operation will appear on the top line of the display. Press the "Enter" button to begin the
selected operation.
CONTINUOUS TEST
This will continuously empty the gumball machine, then load up to 3 balls into the gumball
machine. It will do this until an error is encountered or until the "Escape" button is pressed.
DISPENSE 1 GUMBALL
This will dispense 1 gumball from the gumball machine. During correct operation, you will
see the "Geneva" switch, followed by the "Exit" switch as the gumball rolls out onto the
playfield.
EMPTY GUMBALL MACHINE
This will dispense all balls from the gumball machine.
LOAD 1 GUMBALL
This will load 1 ball from the lower trough into the gumball machine.
Errors:
NO BALLS FOUND IN MACHINE
This error occurs during the Continuous Test when it cannot find any balls to cycle through
the gumball machine.
CHECK GUMBALL ENTRY OPTO
This error occurs if the gumball machine entry opto is not seen after kicking a ball from the
gumball popper.
CANNOT AUTO-LOAD. CHECK AUTO-FIRE
This error occurs if the auto-fire kicker does not get its ball into the gumball machine 4 times
ina row.
CHECK GENEVA SWITCH
This error occurs if the geneva switch is not seen on the dispense of a gumball.
CHECK EXIT SWITCH
This error occurs if the geneva switch and camera switch are seen in a gumball dispense,
without the exit switch ever making.
NO BALL IN TROUGH TO LOAD
This error occurs when a request to load a ball into the gumball machine is made while there
are no balls in the trough.
CANNOT AUTO-LOAD CHECK BALL SERVE
This error occurs during the Continuous Test if the game cannot seem to get the balls from
the trough to the auto-fire kicker.
CHECK BALL POPPER
This error occurs when the ball popper opto appears to be continuously interrupted. This
condition will occur
if
the opto is disconnected, or
if
a 12V fuse is blown (F115, F116).
CHECK AUTO-FIRE KICKER
This error occurs when the auto-fire kicker opto appears to be continuously interrupted.
This condition will occur if the opto is disconnected, or
if
a 12V fuse is blown (F115, F116).
Twilight Zone 1-21
