CLOCK REMOVAL AND REPLACEMENT
Underside of PJayfield, Viewed In Raised Position
Access Hole
Step 2
ClockAss'y
Step 3
1. Turn power switch OFF.
2. Raise the playfield and disconnect the 3 connectors that make up the wiring harness for the clock.
3. Lower the playfield. Remove the phillips screw located on the front base of the clock. Carefully
slide the clock backwards about
1/2
inch. The clock should now be free.
4. Lay the clock on the playfield and remove the 2 nuts that hold the playfield plastic down in the area
of the clock. Remove the plastic.
5. Pull the clock harness through the playfield to complete removal.
6. Replacement is the reverse of removal. Be careful during replacement that the locking tab on the
base of the clock slides into and under the notch of the roof of the player piano scoop.
Twilight Zone 1-50
