MINI-PLAYFIELD (POWERFIELD)
REMOVAL AND REPLACEMENT
Underski« of Play/ie/d, Viewed In Raised Position
Access holo
Step2-
Step 5
Step 4
1. Turn power switch OFF.
2. Raise the playfield. On the left side of the playfield about halfway back there is an access hole for
the mini-playfield wiring harness. This harness has 4 connectors. Unplug all 4 connectors.
3. Lower the playfield. Leave playfield in its most forward position for easier access to mini--playfield.
4. On the top of the side switch mounting brackets there are 2 nuts, loosen, but do not remove these.
5. Remove the screw that holds the wire chute to the mini-playfield. This screw is located between the
chute rails at the mini-playfield entrance.
6. Slide the mini-playfield forwards while working the wiring harness through the playfield.
7. Installation is the reverse procedure from removal.
Twilight Zone 1-58
