A-14039
Dot Matrix Controller Assembly
Part Number
Ckt Designator
Description
'-.---~.
5010-08991-00
Rl
Resistor, 4.7Kn,
1/4w, 5%
5010-09224-00
Rl0
Resistor, 270n,
1/4w, 5%
5010-12832-00
R3, R6, R12, R13
Resistor, 47Kn, 1I2w, 5%
5010-12841-00
R4,R5
Resistor, 120n,
1/2w, 5%
5012-12830-00
R9
Resistor, 1.8Kn, 5w, 5%
5012-12842-00
Rll
Resistor, 120n, 5w, 5%
5012-12843-00
R8
Resistor, 4.7K, 5w, 5%
5010-10171-00
R7
Resistor, 56n,
1/4w, 5%
5040-08986-00
C3
Capacitor, looJ.1fd., 10v,
(±2O"k)
5040-12324-00
C4,C7
Capacitor, 15OJ.1fd.,160v, (±50%)
5043-08980-00
BYPASS
Capacitor, .01J.1fd.,50v, (+80, -20"/0)
5043-09072-00
C6,C9,Cl0
Capacitor, .1J.1fd.,500v, (+80, -20%)
5043-09845-00
Cl,C2,Cll
Capacitor, lKP, SOv, (±20%)
5043-09492-00
C5,C8
Capacitor, lOOP, 50v, (±10%)
5070-09054-00
07
Diode, lN4oo4, 1.0A.
5075-12824-00
06,08
Zener, 1N4 742A, 12v
5075-12823-00
04,05
Zener, lN4758A, 62v
5075-12826-00
03
Zener, lN4759A, 62v
5100-12833-00
BR1, BR2
Bridge, 400v, 1A.
5160-10269-00
01
Transistor, 2N3904 NPN
5164-09056-00
02, 010
Transistor, MPS002, NPN
5164-12154-00
03,07
Transistor, MJE15030 NPN
5194-09055-00
04,05
Transistor, MPS052 PNP
5194-12155-00
06
Transistor, MJE15031 PNP
5281-09738-00
U16, U25 - U27
IC,74LS157
5281-10033-00
U3
IC,74LS30
5281-10043-00
U31 - U33, U35
IC,74LS175
5311-10946-00
U4,U5,U17,U18,U20
IC,74HC74
5311-10947-00
U9
IC,74HC125
5311-10951-00
Ul0, Ull
IC,74HC161
5311-109n-oo
U6
IC,74HC04
<c::>
5311-12817-00
U29
IC,74HC165
5311-12819-00
U21
IC,74HC688
5311-12820-00
U23
IC,74HC27
5311-12822-00
U13-U15
IC,74HC193
5315-12009-00
U22
IC,74HCT374
5315-12812-00
ur.
U2, U30
IC,74HCT138
5281-09308-00
U28
IC, 74HCT245
5315-12815-00
U8,U34
IC,74HCT08
5315-12816-00
U19
IC,74HCT32
5315-12821-00
U7
IC, 74HCT240
5340-12278-00
U24
SlRAM 2064 150NS
5551-09822-00
Ll
INO 4.7J.1H,3.0A.
5671-09019-00
010
Display LED Red
5705-09199-00
03,06,
07
Heatsink 6030B
5731-12328-00
F601,F602
Fuse, 3I8A.,S8, 250v
5733-12060-00
Fuse Holder (F601, F602)
5791-10850-00
J602
Connector, 26-pin STR Sq.
5791-10862-05
J605
Connector, 5-pin Header Sq.
5791-10862-07
J606
Connector, 7-pin Header Sq.
5791-10862-08
J604
Connector, 8-pin Header Sq.
5791-12516-00
J601
34 Hen 17x2 STR
5791-12827-00
J603
14 Hen 7x2 STR
5010-09036-00
R14-R23
Resistor,
ioon
1I4w, 5%
4006-01003-06
03,06,
07
Mach. Screw, 6-32 x
3/8
4406-01128-00
03,06,
07
Nut, 6-32 KEPS
Twilight Zone 2-12
