8 Driver P.C.B. Assembly
A-16100
1
6
le.eeool
J2
1
4
1
0
•
00
1
J5
1
7
looooe.ol
J3
J4
loocc.col
7
J2-1 Black-White from J114-7
J2-2 Key
J2-3 Gray from J114-3
J2-4 Black, Ground from J1 03-2
J2-5 Black, Ground from J1 03-1
J2-6 Gray-Green from J114-1
J4 -1 Not Used
J4 -2 Brown-White to Flasher, Sol. 37
J4 -3 Key
J4 -4 Black-White to Flasher, Sol. 38
J4 -5 Orange-White to Rasher, Sol. 39
J4 -6 Yellow-White to Flasher, Sol. 40
J4 -7 Not Used
J1-1 Ribbon Cable, Data from J204
J5-1 Gray-White, Column 9, drive to clock optos
J5-2 Key
J5-3 Not Used
J5-4 Violet-White to J1-1, A-16120
J3-1 Not Used
J3-2 Green-White to Flasher, Sol. 41
J3-3 Blue-White to J1-2, A-16120
J3-4 Not Used
J3-5 Not Used
J3-6 Key
J3-7 Not Used
r---------~
r-------~
1 CPU BOARO
1
1 ~::'
DRIVER
1
1
I'
1
1
b
~Rlbbon Cable1
!::i:
1 RED-WHT
J
2
~
::
~
1
••••
Co>
1
1
L.. - - - - - - - - - -I
J114 J103
:_ 7 3 1 2 1
I
J1
MINUTEOPTO
b
P.C.B. ASSY.
A-18220
<-
Co>
D.C. MOTOR
:
CONTROL BD.
A-16120
Twilight Zone 3-12
