RAMP LOCATIONS
Item Part Number
Part Number
1.
2.
3.
4.
a)
b)
5.
6.
a)
b)
7.
a)
b)
8.
9.
10.
A-16059
A-16164
A-16056
A-16062
03-8506
03-8506-1
A-16174
A-16133
5647-12693-13
A-16535
A-16060
5647-12693-21
A-13627-2
12-7104
A-16058
03-8826
Cross-Over Chute Assy.
Lock-Up Ramp Assembly
Right Chute Assembly
Center Ramp
&
Opto's Assy.
Opto Mtg. Base - Black
Opto Mtg. Base - White
Shooter Ramp Assembly
Main Chute Ass. (Under plfd.)
Miniature Switch ( 3 used)
Ramp Prox Opto Sensor PCB
Main Ramp Assembly
Miniature Switch
Switch Gate Assembly
Mini-Feed Wire Chute
Mini-Inside Wire Chute Assy.
Small Chute Assy. (Under plfd.)
o
Twilight Zone 2-57
