Coin Door Assembly
U.S.A.Door with Decals
09-17002-x 2-ChuteDoor
09-17003-x 3-ChuteDoor
("x· is the country designator)
Item Part No.
Description
Quantity
1
27-1038
Button Cover
20r3
2
27-1041-1 58 Price Panel
20r3
3
27-1026-1 17 Coin Entry Plate
20r3
4
27-1016
Lock Assembly
1
5
27-1061-1
Coin Return - Bezel
1
6
27-1062
Coin Return Flap
1
7
27-1021
Button Housing - 2-slot
1
27-1022
Button Housing - 3-slot
1
8
27-1111
Interlock Switch
1
9
27-1006-1
Coin Door, 2-Slot
1
27-1007-1
Coin Door, 3-Slot
1
10
27-1005
Coin Door Frame
1
11
27-1003
M/C Screw. 6-32 x 3/16
4
12
5641-12724-00
Diagnostic Switch
1
13
27-1101
MlC Screw, 4-40 x 1/4
2
14
01-9885
Bracket. Diagnostic Switch
1
15
27-1037
Plastic Button
1
16
27-1078
MlC Screw, 6-32 x 3/8
2 or 3
17
27-1039
Conical Spring
20r3
18
27-1079
Self-tapping Screw, #6 x 1/4
2
19
27-1077-1
Coin box Cover
1
20
27-1066
Slam Switch
1
21
27-1067
MlC Screw, 4-40 x 1/2
2
22
27-1017
Nut (key)
1
23
27-1012
Locking Cam
1
"
24
27-1011
Locking Arm
2
._~_8
25
27-1020
Washer
1
26
27-1018
Star Washer
1
27
27-1019
MlC Screw, 1/4-28 x 5/16
1
28
27-1089
R-Ring
1
29
27-1083
Retainer
1
30
27-1081
Coin Inlet Chute
2 or 3
31
27-1088
Cable Clamp
20r3
32
27-1025
Key
Hook
1
33
27-1086
Washer. #6
20r3
34
27-1078
MlC Screw. 6-32 x 3/8
1 or 2
27-1113
MlC Screw, 6-32 x 7/16
1
35
27-1079
Self-tapping Screw, #6 x 1/4
20r3
36
27-1084
Lamp Socket
20r3
27-1085
Lamp
20r 3
37
27-1096
Self-tapping Screw, #5 x 3/8
20r3
38
27-1087
MlC Screw, 6-32 x 5/8
20r3
39
27-1082
Lever Arm
20r3
40
27-1097
Switch Cover
2or3
41
27-1091-1
Coin Accept Chute
20r3
42
27-1075
Wire Form (Small)
2 or 3
or
27-1093
Wire Form (large)
43
27-1094
MlC Screw, 4-40 x 7/8
4 or 6
44
27-1087
MlC Screw, 6-32 x 5/8
4 or 6
45
27-1086
Washer, #6
4 or 6
46
27-1095
Nut. 4-40 ESNA
40r6
47
27-1076-1
Coin Return Box
1
48
27-1078
M/C Screw, 6-32 x 3/8
2
49
27-1092
Microswitch
20r 3
~ ~ ,~ /
Twilight
Zone 2-42
