Flipper Assembly Parts List--Single Switch, Top-Left Flipper
Part No. A365-05040-0oo1
I
'I
Ii
Item Part Number
Description
Oty
1
0171-097P6-AXPC Capacitor: 0.01UF/500V ceramic disc
1
2
0017-00101-0184
#8-32 x
3/8"
hex head screw
9
3
0017-00101-0816
# 10-32 x
3/8"
slotted hex head screw
2
4 1A365-ooo24-oooo
Core plug and bracket assembly
1
5
~C70-00026-oooo
Coli and tubing assembly: 3-lug
1
A365-00067-oo21
Coil: 3-lug
1
00
17-00041-0605
Tubing: Coil, L
=
1.686
x 5/8"
1
5070-09054-00
Diode, 1N4oo4GP,400VAC,
1A
2
6
0017-00104-0073
Washer: Spring: 0.515"
10,
0.875"
00,
0.13" tho
1
7
0360-oo318-ooXF
Coil bracket
1
8
0365-00101-ooXF
Flipper mounting bracket
1
9
4005-01016-07
#5-40 x
7/16"
Phillips round head screw
2
10
0020-00202-0000
Switchplate
1
11
A365-00315-0400
Switch assembly for flipper mechanism
1
12 00
10-00275-0353
Extension spring
1
13
0360-00 145-ooXF
Switch bracket
1
14
0360-00718-ooXF
Plunger
1
15
0360-00945-0000
Tubing:
5/16
x 1/2"
1
16
A360-ooo38-oo00
Lever arm hub and cap assembly: left
1
0017-00101-0186
Setscrew
2
17
0017-00042-0413
Flipper bearing
1
18
0017-00042-0418
Nyliner: snap-in coil type
1
19
0360-oo152-01XF
Left flipper stop bracket
1
5-7
