3) Use a socket to remove flat nuts holding base on motor shaft.
4) Lift off trunk base from shaft.
5) Loosen set screw and pull off opto interrupter. Remove lock nuts (4) holding opto board.
6) Remove hex posts (4).
7) Remove motor base from playfield. The motor can be unfastened and replaced.
8) Remember to reattach the shaft collars to the new motors.
9) Perform the steps in reverse to reassemble the trunk mechanism .
.3) Nuts holding base
I
I
==r=
6)
Hex Posts
(4)
5)
Opto Set Screw
end Lock Nut, (4) \
I
I
rn
m
FIG. 3
1-52
Trunk Base
Motor Base Nuts
8)
Motor Collars
