Remove the Trapdoor Lid
1) To remove the Trapdoor lid, raise the trapdoor shaft and thru the access hole loosen and take out the
screw fastener on the Release Collar.
2) Gently lift the lid assembly up and out of the playfield.
(2) Lid Assy
Lock Switches
Ball Locking Trough
Bali Release Coil Assy.
Boll Popper Switch
FIG. 2 Front View
1-48
D-~
(1) Remove fastener
on Release Collar
Trapdoor Raise Coil
Shaft Assy
