Power Driver Board
A-12697-3
~
'
5,
5
c=l ~
J112
JIll
~
rn
=
-
.
e
c
c
•
e
n
"'
,
J 1
5
81
000
••
1
J108
.1106
I: •.•• :1
J1G7
Jl04
-me
~
.
<;
•
-
.
o
~ 0
J120
J123
J12.c
10
D D
a
Q
C
c.
C C Df
10
C
c.
~II
c.
0 0"
I
, 1
1 5
"
1
JI22
J125
J127
lecoco.cccl
!ccaooc;u:I.ol
g
'9
1
J126
J128
J12111
Joooo.ooocccoollo.ooolloo.ool
13
1 5
1 5
,
J101-1 Red 9VAC from xfrmr secondary
J101-2 Red 9VAC from xfrmr secondary
J101-3 Key
J101-4 Blue-White 13VAC from xfrmr secondary
J101-5 Blue-White loop from J101-4
J101-6 Blue-White 13VAC from xfrmr secondary
J101-7 Blue-White loop from J101-6
J102-1 White-Red loop from J102-2
J102-2 White-Red 16VAC from xfrmr secondary
J102-3 White-Red loop from J102-4
J102-4 White-Red 16VAC from xfrmr secondary
J102-5 Black-Yellow loop from J102-6
J102-6 Black-Yellow 16VAC from xfrmr secondary
J102-7 Key
J 102-8 Black-Yellow loop from J 102-9
J102-9 Black Yellow 16VAC from xfrmr secondary
J
1
03 Not Used
J104-1 White-Blue 50VAC to J901-1,2
J104-2 White-Blue 50VAC to J901-3,5
J104-3 Key
J104-4 Not Used
J104-5 Not Used
J
105 Not Used
J 106-1 Not Used
J 106-2 Not Used
J 106-3 Not Used
J106-4 Key
J106-5 Red-White +20V to insert flash lamps
J107-1 Red-Orange 50V to playfield coils
J107-2 Red-Brown 50V to playfield coils
J107-3 Red-Black 50V to playfield coils
J107-4 Key
J107-5 Not Used
J107-6 Red-White +20V to playfield flashlamps
J
108 Not Used
J
1
09 Not Used
J110 Not Used
J111 Not Used
J112-1 White-Green 9.8VAC from xfrmr secondary
J112-2 White-Green loop from J112-1
J112-3 White-Green 9.8VAC from xfrmr secondary
J112-4 Key
J 112-5 White-Green loop from J 112-3
3-26
