A-19778
Magic Trunk Assembly
5
Item Part Number
Description
1 04-10001
2 01-13627
3 04-10003
4 20-10197
5 04-10002
6 02-4436-29
7 4008-01168-06
8 02-5153
9 20-8712-25
10 03-8042
*
11 31-2255-3
**12 RM-22-30
Trunk Base Bracket
Bracket, Trunk Ball Deflector
BrackeVPole Assembly
Coil Magnet
Trunk Magnet Cover Plate
F-F Spacer #8-32
x
3.88" Long
Mach. Screw, #8-32
x
3/8"
Trunk Magnet Shaft
"E"
Ring,
1/4"
Shaft
Nylon Washer
Decal
Tape - Double Sided
Associated Assemblies:
13
14
15
03-9317
A-20029
4008-01021-07
Magic Trunk
Trunk and Light wlCable
Mach. Screw, 8-32 x
7/16" (4)
• Not available for individual sale. Order Decal Set 31-2255 .
•• Not shown.
2-24
