J113 Ribbon Cable data to/from J211
J114·1 Gray-Green +12VDC to J210-7
J1 14-2 Gray-Green +12VDC to J904-2; J210-6
J114-3 Gray +5VDC to J3-3 Sound Bd; J21 O·S
J 114-4 Gray +5VDC to J3-1 Sound Bd; J904-1; J21 0-4
J114-5 Black Ground to J3-5 Sound Bd; J904-5; J210-3
J114·6 Key
J114·7 Black Ground to J3-4 Sound Bd; J904-4; J210-1
J115-1 Yellow-White 6.8VAC from xfrmr secondary
J115-2 White-Brown 6.8VAC from xfrmr secondary
J 115-3 White-Brown loop from J 115-2
J115-4 White-Orange 6.8VAC from xfrmr secondary
J 115-5 White-Yellow loop from J 115-6
J11S-6 White-Yellow 6.8VAC from xfrmr secondary
J 115-7 Orange 6.8VAC from xfrmr secondary
J115·8 Orange 6.8VAC loop from J115-7
J1 15-9 Key
J115-10 Green 6.8VAC from xfrmr secondary
J1 15-1 1 Brown 6.8VAC from xfrmr secondary
J1 15-12 Brown 6.8VAC loop from J 115-11
J116-1 Key
J1 16-2 Gray·Yeliow +12VDC to playfield
J116-3 Black Ground
J 116-4 Gray +5VDC to playfield
J117-1 Key
J117-2 Gray-Yellow +12VDC to J606-6,7
J 117-3 Black Ground to J606-1 ,3
J117-4 Gray +5VDC to J606-4,S
J118·1 Key
J1 18-2 Gray-Yellow +12VDC to cabinet
J 118·3 Black Ground
J118·4 Not Used
J119·1 White·Violet 6.8VAC G.I. to A·17051-1 J2·3
J119·2 Key
J119-3 Violet Return G.I. to A-17051-1 J2-S
J120-1 Brown Return G.I. to playfield
J120·2 Orange Return G.I. to playfield
J120-3 Not Used
J120-4 Key
J120-S Not Used
J 120-6 Not Used
J120-7 White·Brown 6.8VAC to playfield
J 120-8 White-Orange 6.8VAC to playfield
J 120-9 Not Used
J120-10 Not Used
J120-11 Not Used
J121-1 Not Used
J121-2 Not Used
J121-3 Yellow Return G.I. to insert
J121-4 Key
J121-5 Green Return G.I. to insert
J121-6 Violet Return G.I. to insert
J121-7 Not Used
J121-8 Not Used
J121-9 White·Yeliow 6.8VAC to insert
J121-10 White-Green 6.8VAC to insert
J 121·11 White·Violet 6.8VAC to insert
J122-1 Blue-Brown Sol 2S to playfield flashlamp
J122-2 Blue-Red Sol 26 to playfield flashlamps
J122-3 Blue-Orange Sol 27 to playfield flash lamps
J122·4 Blue-Yellow Sol 28 to playfield flashlamps
J 122-5 Not Used
J 122-6 Not Used
J122-7 Key
J 122-8 Not Used
J 122-9 Not Used
J123 Not Used
J124-1 Blue-Brown 50125 to insert flashlamp
J124-2 Blue-Red Sol 26 to insert flash lamp
J124-3 Blue-Orange 50127 to insert flash lamp
J124-4 Key
J124-5 Blue-Yellow 50128 to insert flash lamp
J 125 Not Used
J 126-1 Black·Brown Sol 17 to playfield motor
J 126-2 Black-Red Sol 18 to playfield motor
J126-3 Not Used
J126-4 Black-Yellow 50120 to playfield flash lamps
J
126-5 Blue-Green Sol 21 to playfield coil
J 126-6 Not Used
J126-7 Not Used
J126-8 Blue-Gray Sol 24 to playfield flashlamps
J126-9 Key
J12S-10 Not Used
J126-11 Not Used
J126-12 Not Used
J126-13 Red-Orange Tieback Diode from J107-1, to
50121
J127·1 Brown-Black 5019 to playfield coil
J127-2 Key
J127-3 Brown-Red Sol 10 to playfield coil
J 127-4 Brown-Orange Sol 11 to playfield coil
J127·5 Brown-Yellow 50112 to playfield coil
J127·6 Brown·Green 50113 to playfield coil
J127-7 Brown-Blue 50114 to playfield coil
J127-8 Brown-Violet Sol 15 to playfield coil
J127-9 Brown-Gray Sol 16 to playfield coil
J128 Not Used
J129 Not Used
3-27
