2. With the main playfield in its service position (i.e. tilted up and moved forward resting on its support
brackets). grasp the front edge of the mini-playfield and swing it up and over its hinge point and
rest it against the back box. (See Fig. 2)
3. All required service and maintenance required can be performed on the mini play-field while it is in
this position.
BACK
PANEL
MINI PLAYFIELD
ASSEMBLY
BACK
BOX
MAIN PLAYFIELD
IN SERVICE POSITION
CABINET
Fig. 2
1-56
