J127-1 Brown-Black Sol 9 to playfield coil
J127-2 Key
J127-3 Brown-Red Sol 10 to playfield coil
J127-4 Brown-Orange Sol 11 to playfield coil
J127-5 Brown-Yellow Sol 12 to playfield coil
J127-6 Brown-Green Sol 13 to playfioeld coil
J127-7 Brown-Blue Sol 14 to playfield coil
J127-8 Brown-Violet Sol 15 to playfield coil
J127-9 Brown-Gray Sol 16 to playfield coil
J 128 Not Used
J129 Not Used
J130-1 Violet-Brown Sol 1 to playfield coil
J 130-2 Violet-Red Sol 2 to playfield coil
J130-3 Key
J130-4 Violet-Orange Sol 3 to playfield coil
J130-5 Violet-Yellow Sol 4 to playfield coil
J130-6 Violet-Green Sol 5 to playfield coil
J130-7 Violet-Blue Sol 6 to playfield coil
J130-8 Violet-Black Sol 7 to playfield coil
J130-9 Violet-Gray Sol 8 to playfield coil
J131 Not Used
J 132 Not Used
J133 Not Used
J134-1 Not Used
J134-2 Not Used
J134-3 Key
J134-4 Not Used
J134-5 Not Used
J 134-6 Not Used
J134-7 Red-Blue Row 6 to cabinet lamp
J134-8 Red-Violet Row 7 to cabinet lamp
J134-9 Red-Gray Row 8 to cabinet lamp
J135-1 Red-Brown Row 1 to playfield lamps
J135-2 Red-Black Row 2 to playfield lamps
J135-3 Key
J135-4 Red-Orange Row 3 to playfield lamps
J135-5 Red-Yellow Row 4 to playfield lamps
J135-6 Red-Green Row 5 to playfield lamps
J135-7 Red-Blue Row 6 to playfield lamps
J135-8 Red-Violet Row 7 to playfield lamps
J135-9 Red-Gray Row 8 to playfield lamps
J136-1 Key
J136-2 Not Used
J136-3 Yellow-Gray Col 8 to insert lamps
J137 Not Used
J 138-1 Yellow-Brown Col 1 to playfield lamps
J138-2 Yellow-Red Col 2 to playfield lamps
J138-3 Yellow-Orange Col 3 to playfield lamps
J138-4 Yellow-Black Col 4 to playfield lamps
J138-5 Yellow-Green Col 5 to playfield lamps
J138-6 Yellow-Blue Col 6 to playfield lamps
J138-7 Yellow-Violet Col 7 to playfield lamps
J138-8 Key
J138-9 Yellow-Gray Col 8 to playfield lamps
3-29
