TROUGH 7 IRED PCB ASSEMBLY
A-18617
J1-1 Not Used
J1-2 Gray-Green, from Opto SW10 Board J1-3
J1-3 Gray-Black, from Opto SW10 Board J1-4
J1-4 Gray-Orange, from Opto SW10 Board J1-5
J1-5 Gray-Red, from Opto SW10 Board J1-6
J1-6 Gray-Brown, from Opto SW10 Board J1-7
J1-7 Gray-Blue, from Opto SW10 Board J1-2
J1-8 Key
J1-9 Black, from Opto SW10 Board J1-9
LED1
o
o
o
o
o
LED3
0
0
LED4
o
Jl
LED 7
~~ (BALL 6)
LED 6
~ (BALL 5)
LED 5
~ (BALL 4)
LED 4
~ (BALL 3)
LED 3
~ (BALL 2)
LED 2
~~ (BALL 1)
Jl
LED 1
BALL 6,
~ (JAM BALL)
BALL 5 2
BALL 4 3
BALL 3 4
BALL 2 5
BALL 1
JAM BALL ~
KEY
cOMM'ON
8
9
'--
3-16
