Page 112 - The Shadow

Basic HTML Version

A-15849-R-4
Flipper Assembly
Jmm
Part Number
Description
.!tml
Part Number
Description
1 A-13104-R
Flipper Bracket Sub-Assy.
18 A-15848-R
Crank Link Assembly, Right
2 SW-1A-194
Switch Assembly
a)
A-17050-R
Flipper Crank Assembly, Right
3 4701-00002-00 Lockwasher, #6 Split
b)
A-15847
Flipper Link Assembly
4 4105-01019-10 Sh. Metal Screw, #5 x 5/8"
c)
02-4676
Link Spacer Bushing
5 4008-01079-05 Mach. Screw, 8-32 x 5/16"
d)
4010-01086-14 Cap Screw, 10-32 x 7/8"
6 4701-00003-00 Lockwasher #8 Split
e)
4700-00023-00
Flatwasher, 5/8 x 13/64 x 16ga.
7 01-9375
Switch Mounting Bracket
f)
4701-00004-00 Lockwasher #10 Split
8
20-6516
Speednut, Tinnerman
g)
4410-01132-00 Nut, 10-32 ESN
9
4010-01 066-06
Cap Screw,
10-32
x
318"
19 23-6577
Bumper Plug, 5/8"
10 4701-00004-00 Lockwasher #10 Split
20 03-7568
Flipper Bushing
11 A-12390
Flipper Stop Assembly
12 FL-15411
Flipper Coil, Orange
a) 03-7066-5
Coil Tubing
Associated Parts:
13 01-7695
Solenoid Bracket
(Not Shown)
14 4006-01017-04 Mach. Screw, 6-32 x 1/4"
15
10-364
Spring
21 23-6519-4
Flipper Rubber Ring, Red
16 4006-01005-06 Mach. Screw, 6-32 x
318·
22 20-9250-5
Flipper & Shaft
17 4406-01117-00 Nut, 6-32 Hex
A-15849-R-2
Flipper Assembly
(Parts listed replace same items of A-15849-R-4)
.IWn
Part Number
Description
.
.
12 FL-11629
Flipper Coil, Blue
Flipper Notes ...
1. Each Flipper Assembly is mounted beneath the playfield, in conjuction with the Plastic Flipper
&
Shaft,
and Flipper Rubber on the upper side of the playfield.
2.
With the flipper, in the non-activated position, the E.O.S. Switch contacts must have a gap of
.062 (:t.01S)
inch.
When flipper is activated switch must close.
3. Any adjustment of the E.O.S. switch must be made at a minimum distance of
0.25
inch from the switch body.
4. Longer blade of E.O.S. switch must be made straight. Gap adjustment is done by adjusting shorter blade.
5. All moving elements of the assembly must operate freely without any evidence of binding.
6. Apply Loctite™ 245 when reataching screws to the Flipper Stop Assembly, the Solenoid Bracket,
and the Flipper Bushing.
2-17
