A-16120
D.C. Motor Control PCB Assembly
~~G
I
11
I
.~
@.~ ~
.---
::
-
c...
~
~8
...•
"
[l}
:::>
"""')
0
*
0
0
8~B~
'--
-~I
I~
0
L2
Part Number
5768-13402-00
5791-12273-04
5791-12273-05
5671-13732-00
5070-09054-00
5551-09822-00
5010-09061-00
5010-10255-00
5010-08997-00
5010-09085-00
5040-1 0974-00
5370-13342-00
5490-1 0892-00
5250-09157-00
5043-08980-00
5041-09031-00
5281-09500-00
5043-08996-00
Designator
J2
J1
LED1
01,02,03
L1,L2
R2,R6
R5
R3,R7,R8
R1
C3
U4
U1, U2
Q1
C2, C4, C6, C7, C8
C1
U3
C5
2-15
Description
PCB DC Motor Control Board
4H Str. Sq. Lock. 156
5H Str. Sq. Lock .156
Display Red LED
Diode 1N4004 1.0A
Indicator 4.7 mH 3A
Resistor 680 1/2w 5%
Resistor 10 1/2w 5%
Resistor 2.7K 1/2W 5%
Resistor 1.5K 1/4w 5%
Capacitor 100 mfd 35V Rad
IC 3A DMOS Bridge Drive
Opto Isolator 4N25)
Regulator 7805 1A 5V
Capacitor .01 mfd 50V +80/-20
Capacitor 1mfd 25V +/-20 Axial
IC 74LS32 Quad OR
Capacitor.1 M 50V +/-20
