Minimum Volume Control
The operator chooses whether the volume can be turned Off. The choices are:
YES
NO
Volume can be turned Off.
Volume can be turned Down but not Off.
General Illumination Power Saver
This adjustment allows the general illumination and controlled lamps to be
dimmed following a time interval after a game is played. Power Saver Level (A.1
30) determines how dim the lamps will get. The use of this feature will
substantially increase the life of the lamps.
Settings: Off
2-60 Minutes
t . t
Power Saver Level
When General Illumination Power Saver (A.1 29) is set to On, this adjustment
controls the intensity of the G.1. and controlled lamps once the game has been
idle for a specified period of time.
Settings:
4-7
Ticket Expansion Board
When a WilliamslBally Ticket expansion board is connected to a game, fun control
of the ticket dispenser is available, including a ticket low/error indication lamp,
resume on ticket jam, and manual ticket dispense. When the ticket board is
attached, this adjustment should be set to yes.
Press the Escape button to return to the Adjustments Menu. Press the Up button to advance to
the next desired Adjustments Group, (or press the Down button to return to a previous group).
Press the Enter button to activate. Use the Up or Down button to cycle through the available
adjustments.
- ; , . .$. .
PARTY ZONE 1-12
