SOLENOID IFLASHER LOCATIONS
.bm
Coillflasher
Assy. No.
N2&
01 AE-26-1200
02 AE-26-1200
03 AE-26-1500
04 AE-26-1200
05 AE-26-1200
06 AE-30-2000
07 AE-23-800
08
09 AE-27-1200
10 AE-26-1200
11 AE-26-1200
12 AE-26-1200
13 AE-26-1200
14
15 AE-26-1500
16 AE-26-1500
17 24-8802
18 24-8802
19a 24-8704
19b 24-8704
20 24-8802
21 24-8802
22 24-8704
24-8802
23 AE-26-1500
24 14-7968
25 24-8704
26 24-8704
24-8802
27 24-8704
24-8802
28 24-8802
A-14863
0-11335-4
A-14757
B-9362-L-2
A-14808
A-14983
B-10686-1
A-8039-3
B-9362-L-2
A-12842-4
A-12842-4
A-12842-4
B-11203-R-1
B-11203-L-1
A-14495
C-13337
A-8798
A-9302
A-12336-1
C-13337
A-8798
A-14766
A-14766
A-9302
A-8798
A-8798
A-12336-1
General illumination Circuits
·01 24-6549
·02 24-6549
·03 24-6549
·04 24-8768
·05 24-8768
•
FL-11630
FL-11630
•
"Not Shown
A-11905
A-11905
A-11905
Description
Back Ball Popper
Right Ball Popper
D.J. Mouth
D.J. Eject
Dancin' Dummy
Comic Mouth
Knocker
Not Used
Outhole
Ball Release
Left Jet Bumper
Right Jet Bumper
Bottom Jet Bumper
Not Used
Left Sling
Right Sling
Cottage Flasher #906
Rocket Flashers #906
Out Of Control #89
Out Of Control #89
Comic Flasher #906
Ozone Flashers #906
Right Side Flashers #89
Backbox Insert #906
Head On/Off
Head Direction 12V
Boppers Flasher #89
Left Side Flashers #89
Backbox Insert #906
Top Left Flasher #89
Backbox Insert #906
D.J. Flasher #906
Left Playfield String #44
Red Playfield String#44
Right Playfield String #44
Bottom Insert String #555
Top Insert String #555
C-13174-L Left Flipper Assy.
C-13174-R Right Flipper Assy.
2.43
o
CJ
oC>
c::::;O
o
0
~O
o
o
oo
o
o
o
o
o
PARTY ZONE
