A-15297 Accelerator Entrance Ramp Assembly
Item Part Number
Description
1.
A-15296
Accelerator Ramp Weldment
2.
01-10614
Plate: Ramp Entrace
3.
07-6688-16N
Rivet: 1/8 x 1/8 Lg. Nic. PIt.
4.
01-10613
Ball Guide, Center Wall
5.
4008-01015-06
Mach. Screw, 8-32 x 3/8 PHL PAN
6.
A-15586
Divertor Pivot Shaft Assembly
7.
A-15569
Divertor Actuator Shaft Assy.
8.
4323-01158-06
SS 1/4-28 x 3/8 Sh. Knurled Cup PI.
9.
A-15605
Coil Stop Bracket Assembly
10.
4408-01119-01
Nut 8-32 ESNA
11.
01-10225
Coil Mounting Bracket
12.
4406-01128-00
Nut 6-32 KEPS
13.
A-14701
Coil Assembly
14.
03-7066
Coil Tubing
15.
02-4606
Shaft, Divertor Actuator
16.
10-128
Spring
17.
20-8712-43
"E"-Ring 7/16"
18.
20-8716-5
Roll Pin, 1/8 x 7/16"
19.
A-14316
Opto PIT Assembly (Black)
20.
A-14315
Opto LED Assembly (White)
21.
4004-01003-06
#4 x 3/8 PHL PAN PT ST
22.
Not Used
23.
4700-00030-00
Flatwasher, 17/64 x 1/2 x 17ga.
24.
4004-01003-10
Mach. Screw, 4-40 x 5/8 P-PH-S
THE GETAWAY 2-30
