A-15205-R Flipper Assembly
(Upper Right)
Item Part Number
Description
1.
B-13104-R
Flipper Base Assy, Right
2.
SW-1A-193
End of Stroke (EOS) Sw.
3.
4701-00002-00
Lockwasher, #6 Split
4.
4105-01019-10
Sh. Metal Screw,#5 x 5/8
5.
4008-01079-05
Mach. Screw, 8-32 x 5/16
6.
4701-00003-00
Lockwasher, #8 Split
7.
01-9375
Switch Mounting Bracket
8.
20-6516
Speednut, Tinnerman
9.
4010-01066-06
Cap Screw, 10-32 x 3/8, SH
10.
4701-00004-00
Lockwasher, #10 Split
11 .
A-12111
Flipper Stop Assembly
12.
FL-11630
Flipper Coil (Red)
a) 03-7066-5
Coil Tubing
13.
01-7695
Solenoid Bracket
14.
4006-01017-04
Mach. Screw, 6-32 x
1/4
15.
10-364
Spring
16.
B-13882-R
Crank Link Assembly, Right
17.
23-6577
Bumper Plug
18.
03-7568
Flipper Bushing
19.
4006-01005-06
Mach. Screw, 6-32 x 3/8
20.
4406-01117-00
Nut, 6-32 Hex.
Associated Parts for Left
&
Right Flippers:
23-6519-4
Flipper Rubber (Red)
20-9250-5
Flipper
&
Shaft (White)
A-15205-l-1
Flipper Assembly
(Lower Right)
(Parts listed replace same items of A-15205-R)
Item Part Number
Description
1.
B-13104-L
12.
FL-11629
16.
B-13882-L
Flipper Base Assy, Left
Flipper Coil (Blue)
Crank Link Assembly, Left
Flipper Assembly Notes ...
1. Each Flipper Assembly is mounted beneath the playfield,
in conjuction with the plastic Flipper Plastic Paddle and
Shaft (20-9250-6) and Flipper Rubber (23-6519-4) on
the upper side of the playfield.
2. With the flipper in the actuaded position the E.O.S. Switch
contacts must have a gap of .062 (±.015) inch.
3. Any adjustment of the E.O.S. Switch must be made
at a minimum distance of 0.25 inch from the switch body.
4.
The lane change switch must have a gap between
contacts of .046 (±.015) when open.
5.
All moving elements of the assembly must operate
freely without any evidence of binding.
6.
Apply Loctite
1M
242 when reataching screws to the
Flipper Stop Assembly, the Solenoid Bracket, and the
Flipper Bushing.
A-15205-R-2
Flipper Assembly
(Lower Left)
(Parts listed replace same items of A-15205-R)
Item Part Number
Description
12.
FL-11629
Flipper Coil (Blue)
THE GETAWAY 2-18
