6. Extend each leg leveler
slightly
below the leg bottom. so that all four foot pads are extended
about the same distance. Remove the cabinet from its support and place it on the floor.
7. Unlock and open the coin door. Locate the Molding Latch Lever. and move the lever toward the
left side of the game. to release the Front Molding. Lift the Front Molding off the playfield cover
glass return the Latch Lever toward the right. and close the coin door. Carefully slide the glass
downward. until it clears the grooves of the Left and Right Side Moldings. Lift the glass up and
away from the game. storing it carefully to avoid breakage.
8. Place a level or an inclinometer on the playfield surface. Adjust the leg levelers for proper
playfield level (side-to-side).
Note:
It is recommended that these measurements be made ON the
playfleld, not the cabinet nor the playfleld cover glass . Tighten the nut on each leg leveler shaft .
Please note the new Tru-Pitch™ level located on the shooter rail. This allows the operator to
accurately pitch the game - without removing the glass - when it is first set in a new location.
The first line on the level is approximately 6 degrees . Every line after that is approximately
another 1/2 degree of pitch. We recommend you pitch the game with the nose of the bubble
between the first and second line on the level (between 6 and 6-1/2 degrees).
! IMPORTANT!
Playfield pitch angle adjustments can affect the operation of the plumb bob tilt, inside the
cabinet. The plumb bob weight is among the parts in the cash box; the operator should install the
weight and adjust this tilt mechanism for proper operation, after completion of the desired
playfield pitch angle setting .
9. Install the Gear Shift Mechanism. Lift the playfield and rest it on the support arm. Place the
Gear Shift into the hole in the cabinet (where the plunger is normally located). Be sure "Shift Up"
is on top. From the front of the cabinet. slide a cap head screw through each of the four holes .
From the inside of the cabinet. slide a washer over each of the four screws. Secure into place with
an ESNAnut. Plug the Gear Shift Cable into the Cabinet Cable. Be sure the wire colors match on
both connectors. Lower the playfield.
4410-01119-00 (4 usedl____
(~PI
~ :~
Nut 10-24 ESN
---c~
r:
. >' / ~
i
~')
' / /
.
4700-00023-00 (4 used)
. /
' Y // /
Flat Washer.203 x .625 x .059
/ /
