Page 129 - The Getaway

Sound Circuits
Wire Color Fynctlon
Ribbon Cable Data J506 To/From CPU Board, Fliptronic II Controller &
Dot Matrix Controller
Gray/Green 20VAC
Gray/Green 20VAC
Gray (center tap)
Gray (center tap)
Gray/White 20VAC
Gray/White 20VAC
Gray +5VDC
Gray +5VDC
Black Ground
Black Ground
Black/Yellow Speaker
Black/Yellow Speaker
Connector From Transformer Secondary
J501-1
J501-2
J501-4
J501-5
J501-6
J501-7
Power From CPU/Power Driver Board
J502-1
J502-3
J502-4
J502-5
Cabinet Speaker Connection
J504-3
Backbox Speaker Connection
J505-2
The Getaway 3-24
