Solenoid Circuits
Connectors From Power Driver Board:
WI[e
Cglg[ Eynctlgn
Ig
ea~kbgx
Ig
~la~lIeld
IransJ:Ug[
Violet/Brown Solenoid 11High Power
J130-1
082
Violet/Red
Solenoid 21 High Power
J130-2
080
Violet/Orange Solenoid 3, High Power
J130-4
078
VioletlY ellow Solenoid 41 High Power
J130-5
076
Violet/Green Solenoid 5, High Power
J130-6
064
Violet/Blue
Solenoid 6, High Power
J130-7
066
Violet/Black
Solenoid 71 High Power
J130-8
068
VioleVGra~ Solenoid 8 1 High Power
J130-9
070
Brown/Black Solenoid 9 1 Low Power
J127-1
058
Brown/Red
Solenoid 10 1 Low Power
J127-3
056
Brown/Orange Solenoid 111 Low Power
J127-4
054
Brown/Yellow Solenoid 121 Low Power
J127-5
052
Brown/Green Solenoid 13 1 Low Power
J127-6
050
Brown/Blue
Solenoid 141 Low Power
J127-7
048
BrownlViolet
Solenoid 15 1 Low Power
J127-8
046
Brown/Gra~ Solenoid 16 1 Low Power
J127-9
044
Black/Brown Sol. 17, Flasher 1, No Diode
J126-1
042
Black/Red
Sol. 18, Flasher 2, No Diode J125-2
J126-2
040
Black/Orange Sol. 19, Flasher 3 1 No Diode J12S-3
J126-3
038
Black/Yellow Sol. 20, Flasher 4, No Diode
J126-4
036
Blue/Green
Sol. 211 S~ecial1 Drive
J125-6
J126-5
028
Blue/Black
Sol. 22, S~ecial 2 Drive
J126-6
030
BluelViolet
Sol. 23, S~ecial 3 Drive
J125-8
J126-7
034
Blue/Gra~
Sol. 24, S~ecial 4 Drive
J125-9
J126-8
032
Blue/Brown
Sol. 25, S~ecial 5 Drive
J122-1
026
Blue/Red
Sol. 26, S~ecial 6 Drive
J122-2
024
Blue/Orange Sol. 27, S~ecial7 Drive
J123-4
022
BluelYellow Sol. 28, S~ecial 8 Drive
J122-4
020
