C-13509-1
High Current Driver Board Assembly
o
o
o
III
o
o
Jl - 1
Black. Ground from Power Driver Board J11S-3
Jl -
2
N/C
Jl - 3
Key
Jl -
4
Brown-Yellow. Solenoid 12 Driver from Power Driver Board J127-5
Jl -
5
N/C
Jl - 6
Violet-Orange. +50V de from Power Driver Board J107-2
J2 - 1
Violet-Orange. to Plunger Kicker Coil
J2 - 2
Violet -Orange, jumper from J2-1
J2 - 3
Brown. jumper from J2-5
J2 - 4
Key
J2 - 5
Brown. from Plunger Kicker Coil
01
r-~~--~~-. ------~3
--=K~----t4
3j-=::.L---
R1
4 f------__._+_~
The Getaway 3-18
1. . -----15
