Reach into the cabinet and backbox and ensure that the interconnecting cables are not kinked or
pinched. Be careful to avoid damaging wires at any stage of the assembly process.
5.
Raise the hinged backbox upright and latch
it
into position. Unlock the backbox, and remove the
backglass.
Remove the shipping screws hOlditlg the Insert Panel. Unlatch and open the Insert
Panel. Carefully
lift
up the Speaker Panel and lay it down on the playfield glass. (Be careful not to
damage the Dot Matrix DisplaylDriver.) This allows access to the bolt holes used for securing the
backbox upright
To
secure
the backbox, install the wasner-nead mounting bolts through the
bottom holes of the backbox into the threaded fasteners in the cabinet Close and latch the Insert
Panel. Replace the Speaker Panel. ReinstaU the backglass, and lock the backbox.
L!).
CAUTION
FAILURE TO INSTALL
the backbox mounting hardware properly can cause personal injury,
NEVER TRANSPORT
a pinball game with the hinged backbox erect
Always lower the backbox
forward onto the playfield cabinet on a layer of protective material to prevent marring or damage
and possible personal injury.
6.
Extend each
H3g
leveler
slightly
below
the leg bottom.
so
that all four foot pads are extended about
the same distance. Remove the cabinet from
its
support and place it on the floor .
• t'
7.
Unlock and open the coin door. Move the molding latch lever toward the left side of the game. Lift
the front molding off the playfield cover glass return the latch lever toward the right, and close the
coin door. Carefully slide the glass downward, until it clears the grooves
of
the left and
right
side
moldings. Lift the glass up and away from the game. storing
it
carefully to avoid breakage.
8.
Place a level or an incrlOometer on the playfield surface. Adjust the leg levelers for proper playfieJd
level (side-to-side).
Note:
This measurement must be made ON the playfield, not the cabinet nor
the playfield cover glass. Tighten the nut on each leg leveler shaft to maintain this setting.
9.
Adjust the leg levelers to the proper playfield pitch (back-to-tront). The recommended pitch level is
6-112
degrees.
!
IMPORTANT!
Playfield pitch angle can affect the operation of the plumb bob tilt. The plumb bob weight. is among
the parts in /.he cash box; the operator should install the weight and adjust this
iilt
mechanism for
proper operation, after completion of the desired playfield pitch angle setting. The un;t ts factory
installed for
a
6·112 degree angle. If an adjustment is necessary, loosen the screw at the bottom
of
the unit. Move the pointer, one grove at
a
time to the Jeft or the right. depending on the degree
desired. Hold the pointer in place and tighten screw.
10.
Move the game into the desired location: recheck the level and pitch angle of the playfield.
11. 6e sure the
required number
of balls are installed. This game uses four balls.
