UPPER PLAYFIELD PARTS
Item
Pan
Number Description
40 12-6466-12 Guide Wire, 3"
41 A-15252-R Flipper Ball Guide Assy.
42 01-10621
Strike Plate
1 20-9250-6
Flipper
&
Shaft, Yellow (3)
03-8633
Level Mounting Bracket
2 A-15252-L Flipper Ball Guide Assy.
20-9691
Level
3
12-6466-5
Guide Wire, 1 1/4"
43
A-15249
Ball Guide Assembly
4
12-6466-6
Guide Wire, 1 1/2"
44
A-8039-3
Ball Release Assembly
5 A-I 5239
Ball Guide Assembly
6 20-9264-6
Small Flipper
&
Shaft
7
A-15199
Opto Ball Guide Assy.
Not Shown:
8 B-1 1696-1
Standup Target, Blue
A-13204-20017
Bottom Arch Assembly
9
A-15197
Opto Ball Guide Assy.
A-15369-1
Playfield Plastic Assy.
10 B-9414-3
Jet Bumper Assembly
A-15369-2
Playfield Plastic Assy.
03-8254-8
Jet Bumper Cap, Amber
A-15369-3
Playfield Plastic Assy.
11 A-15258
Chair Bracket Assembly
A-I 5369-4
Playfield Plastic Assy.
03-8647
Electric Chair
A-I 5369-5
Playfield Plastic Assy.
24-8768
#555 Bulb (2)
A-I 5369-6
Playfield Plastic
Assy.
03-8063-4
Lamp Sleeve, Red
A-15375
Cloud Assembly
03-8063-6
Lamp Sleeve, Yellow
A-8645
Wire Form
&
Bracket
12 B-9414-3
Jet Bumper Assembly
B-8623
Guide
&
Baffle Assy.
03-8254-16
Jet Bumper Cap, Yellow
C-8235
Ball Runway
Assy.
13 B-9414-3
Jet Bumper Assembly
01-3569-1
Ball Return Runway
03-8254-10
Jet Bumper Cap, Blue
01-5575
Bottom Arch Mtg. Brkt.
14 B-1 1696-4
Standup Target, Red (2)
01-8419
Holdown Bracket (2)
15 B-12583-4
Oblong Target, Red (2)
03-7960-20017-1
Full Playfield Mylar
16 B-9414-3
Jet Bumper Assembly
03-7960-20017-2
Jet Area Mylar
03-8651-13
Jet Bumper Cap, Clear
03-7960-20017-3
Drop Area Mylar
17 B-9414-3
Jet Bumper Assembly
20-6500
1 1/16 Steel Ball
03-8254-9
Jet Bumper Cap, Red
31-1002-20017
"Screened Playfield
18
A-15039
Diverter Assembly
31-1664-1 thru 41 Playfield Plastics
19 B-12583-1
Oblong Target, Blue
20 A-I 5246
Ball Guide Assembly
21
A-15241
Ball Guide Assembly
22
A-15244
Ball Guide Assembly
23 B-1 1696-5
Standup Target, White
24
A-15374
Dampening Bracket
25 03-8581
Box Base
03-8582
Box Cover
01-10654
Box Retaining Brkt.
26
A-15247
Ball Guide Assembly
27
A-15243
Ball Guide Assembly
28 12-7026
Guide Bar Wire
29 A-15240
Ball Guide Assembly
*
The ADDAMS FAMILY Diamond Plate™
30 01-10454
Deflector Bracket
playfield does not require a full mylar.
31
A-15251
Ball Guide Assembly
However, mylars can be purchased through your
32
A-14974
Ball Guide, Shooter Ramp
local Bally Distributor.
33
A-14970
Bookcase Assembly
34
A-15248
Ball Guide Assembly
35
A-15.242
Ball Guide Assembly
36
A-15250
Ball Guide Assembly
37 B-11696-15 Standup Target, Orange (3)
38
A-14196
Shooter Gate Assembly
39
A-15245
Ball Guide Assembly
The ADDAMS FAMILY 2-36
