A·12742·20017
WPC CPU Board
Item Part Number
eealgnator
eeacrlptlon
5010-09034-00
R14-R22, R27-R42, R86,
Resistor, 10Kn,
1/4w, 5%
R90,R94,R98
2 5010-09085-00
Rl,R2,R4,R93,R96,R97
Resistor, 1.SKn,
1/4w,
S%
3 SOl 0-09314-00
RS2, R54, R56, R5S, RSO,
Resistor, 1.2Kn,
1/4w,
5%
R62, R64, R66, R75-R82
4 5010-09358-00
R3, R43-RS1, R53, RSS, R57,
Resistor, lKn,
1/4w.5%
R59, R61, R63, R65, R67-R74,
RS4
5 5010-09416-00
R5-RS, R12, R13, R87-RS9
Resistor, 4700,
1/4w, 5%
6 5010-09534-00
Wl, W4, W7. W13 - W18
Resistor, 00
7 5010-10258-00
R95,R99
Resistor, .o1J.1fdO,
1/4w, 5%
S 5010-109S9-00
R92
Resistor, 470Kn,
1/4w. 5%
9 SOl 0-121 04-00
R91
Resistor, 22J.1fd,
1/4w, 5°,4
10 5019-09362-00
SIP 1
SIP, 9R, 10-pin, 4.7Kn. 5%
11 5040-08986-00
C31
Capacitor, l00J.1fd, 10v (±20%)
12 5043-0S980-00
8
Capacitor, .01I-Lfd,SOy, (-tSO, -20%)
13 5043-09030-00
C27
Capacitor, 0.047J.1fd,50v (±20%)
14 5043-09065-00
C3 - C26
Capacitor, 470pfd. 50v (±20%)
15 5043-09491-00
C2, C29, C3O, C34
Capacitor, 22pfd, 1KV, (±10%)
16 5043-09492-00
C2S
Capacitor, 100pfd, 5Ov, (±10%)
17 5043-09845-00
C32, C33
Capacitor, 1KP, 5Ov, (±20%)
18 5070-08919-00
02- 018
Diode, lN4148, 150MA
19 5070-09266-00
Dl.025
Diode. lN5817. 1.0A.
20 5160-10269-00
01
Transistor, 2N3904, NPN
21 5162-12422-00
U20
IC, ULN, 2803A
22 5281-09308-00
U3
IC. 74LS245, Octal Bus Trncv
23 5281-09486-00
U14
IC, 74LS374, 80 F/F
24 5281-09851-00
US
IC, 74LS14, SMTffRG
25 5281-09867-00
U1, U2, U7
IC, Octal Buffer, 74LS244
26 5281-10182-00
uu.
U12, U13, U15
IC, 74LS240 Driver
27 5284-12651-00
U21
IC,4584
28 5340-12278-00
US
StRAM 2064
29 5370-12272-00
U16 - U19
IC, LM339. Quad. Comp
30 5370-12687-00
Ul0
MC. 34064 Reset Chip
31 5520-10438-00
X2
Crystal, S.OMHz.
32 5520-12084-00
Xl
Crystal 32.768 KHz
33 5551-09822-00
L1
ILN, 4.7 UH 3A
34 5671-090 19-00
019-021
OSPLLEO RED
35 5700-08985-00
U4
Socket, IC 40P, .6'
36 5700-12088-00
U6
Socket, IC 32P, .6'
37 5700-12424-00
U9
Socket. 84 Pin PLCC
38 5791-10850-00
J201, J204
Connector, 26-pin Header Sir Sq.
39 5791-10862-07
J210
Connector, 7-pin Header Str Sq.
40 5791-12461-08
J212
Connector, 8-pin Header Str Sq.
41 5791-12461-09
J206 - J209
Connector, 9-pin Header Sq. pin
42 5791-12461-12
J205
Connector, 12-pin Header Sq. pin
43 5791-12516-00
J202, J211
34 Hen 2x17 STR
44 5881-09021-00
81 - B3
Battery Holder' AA'
45 5048-11033-00
C50
Capacitor,0.022I-Lf, 10v
46
'"
PCB Label
47 A-5343-20017-1
U6
Game PROM Assembly
48 5410-12426-00
U9
WPC-89ASIC
49 5400-10320-00
U4
IC MPU 68B09E
50 5880-09022-00
B1 - 83
Battery, Alkaline, 1.5v ('AA')
51
'"
Bare PC Board
Not":
1.
See separate manual for schematics.
2.
lie
=
Not available for individual sale.
The ADDAMS FAMILY 2-6
