B-9361-R-1
Ball Eject Assembly
Associated Assemblies:
Item Part Number
Description
Item Part Numher
Description
1 A-6949-R
Spring Plate
11
B-9362-L-3
Coil
&
Bracket Assembly
2 A-18146
Mounting Bracket Assembly
a) A-17808
Bracket
&
Stop Assembly
3 A-7471-R
Eject Cam Assembly
b) 01-8-508-S
Coil Retaining Bracket
4 02-3407-02
Coil Plunger
c) 4006-01017-06 Mach. Screw, 6-32 x
3/8"
5 10-362
Spring Eject
d) 4406-01119-00 Nut, 6-32 ESN
6 12-6227
Hairpin Clip
e) AE-27-1200
Coil Assembly
7 4700-00030-00 Flat Washer,
17/64
x
112
x 15ga.
f)
03-7066
Coil Tubing
8 4700-00103-00 Flat Washer,
17/64
x
112
x 28ga.
12 10-128
Spring
9 03-8085
Armature Link
*13 03-9101-18
Eject Shield, Tr. Violet
10 20-8716-5
Roll Pin,
1/8
x
7/16"
*Not shown.
2-13
