U.9 Presets
1-21
Game Difficulty Table for U.S., Canadian, French, German,
and European Games
1-21
Preset Table for U.S./Canada
1-21
U.10 Clear Credits
1-23
U.11 Auto Burn-in
1-23
Adjustments
Menu
1-24
A.1 Standard Adjustments
1-24
A.2 Feature Adjustments
1-28
A.3 Pricing Adjustments
1-32
Pricing Table
1-40
A.4 H.S.T.D. Adjustment
1-41
A.5 Printer Adjustments
1-42
Error Messages
1-43
CPU Board
&
Audio Visual Board Error Codes
1-45
Opto Theory
1"45
LED List
1-46
Fuse List.
1-47
Maintenance Information
1-48
Unit Disassembly for Repair-Major Component Service Instructions
1-49
Shooting Star Spike Assembly
1-50
Genie Target Assembly
1-51
Spinning Aladdins Lamp Assembly
1-52
Section 2 - Game Parts
Information
2-1
Backbox Assembly
2-2
Cabinet Assembly
2-3
Audio Visual Board Assembly
2-4
Power Driver Board Assembly
2-6
CPU Security Board
2-8
Coin Door Interface Board Assembly
2-10
Flipper Opto Board Assembly
2-10
Trough LED Board Assembly
2-11
Trough Photo Transistor Board Assembly
2-11
7-0pto Board Assembly
2-12
Ball Eject Assembly .........................•................................................................................
2-13
Flipper Assembly-Left
2-14
Flipper Assembly-Right
2-15
Kicker Arm (slingshot) Assembly
2-16
Outhole Ball Trough Assembly
2-17
Jet Bumper Assembly
2-18
Jet Bumper Coil Assembly
2-19
Tilt Mechanism Assembly
2-20
Knocker Assembly
2-20
Kicker Assembly
2-21
Magnet Diverter Unit Assembly
2-22
