IMPORTANT NOTICE
PLEASE READ
This pinball game is equipped with a SAFETY FEATURE to prevent shocks from
the solenoid circuit when the coin door is opened. An interlock switch assembly
(part no. A-18249-1), located at the left of the coin door opening, has been
added to the game. This assembly is a bracket containing the existing memory
protect switch on the bottom and a new interlock switch on the top. When the
coin door is opened, this new interlock switch opens, breaking the connection to
the +50V and +20V winding of the transformer secondary.
A special tool called the Service Switch Actuator is provided for the
serviceman/technician that repairs the game. This tool is painted yellow and
located in a bag stapled inside the cabinet. The service Switch Actuator slips
over the interlock switch and holds it closed while the coin door is opened,
allowing the serviceman to test and repair the solenoid circuit.
Hold the top interlock switch in, then slide the short end of the Service Switch
Actuator over the top of the interlock switch bracket and the long end over the
center of the switch plunger to hold it in.
SERVICE SWITCH ACTUATOR
(01-11791)
MEMORY PROTECT SWITCH
(5643-09268-00)
----'---__,
BRACKET
(01-12676)
WHT-RED (928)
WHT-RED (92C)
BLK-YEL (04C)
BLK-YEL (048)
______ INTERLOCK SWITCH ASSEMBLY
-----(A-18249-1
)
(A-18249-2,
JAPAN ONLY)
