PINBALL GAME ASSEMBLY INSTRUCTIONS
TALES
OF
THE ARABIAN NIGHTS™ is
a
six ball game.
There are four ball-in-p/ay balls and two captive balls.
Power:
Domestic 120V
@
60Hz
Dimensions:
Width: 29" approx.
Foreign 230V
@
50Hz
Depth: 52" approx.
Japan 100V
@
50HZ
Height: 75" approx.
Temp:
32°F to 100° F, (O°C to 38°C)
Humidit'l:.
Not to exceed 95% relative.
Weight:
325 lb. approx. (crated)
1.
Remove all cartons, parts, and other items from the shipping container and set them aside.
2.
Leg levelers and leg bolts are among the parts in the cash box. Install leg levelers on the front and
rear legs (View 1). Place cabinet on a support and attach rear legs using leg bolts (View 2).
3.
Attach front legs using leg bolts (View 2).
©
H
11
ii
ii
FRONT
o
"
\I
II
Ii
1\
VIEW 1
Detai led View -Leg Lev eler
Leg
- C - l0B43 -B R
VIEW 2
1-2
