Item Part Number
1 A-19963-1
2 B-9362-L-3
"A-178ll
3 A-20742
4 A-20695-1
5 A-20749
6 A-20743
7 A-16434-2
8 A-20691
9 A-20636
10 B-9362-L-3
"B-9361-R-1
11 A-17749.1-2
12 A-9415-2
13 A-17932-1
14 A-18157
15 A-20812
16 A-20642
17 A-17749.1-1
18 A-20744
19 A-20644
20 A-20747
21 A-20746
22 A-14876-R-3
23 A-20745
24 A-15576
25 A-20693
26 A-20748
27 A-20750
28 A-15849-L-2
29 01-11781
Lower Playfield Parts
Description
Ball Trough Assembly
Coil
&
Bracket Assembly (2)
Kicker (Slingshot) Assy. (2)
3-Lamp Board Assembly
Bracket
&
Opto Board Assy.
3-Lamp Board Assembly
5-Lamp Board Assembly
Kicker Assembly
Loop Sub-Assembly
Spinning Lamp Assembly
Coil
&
Bracket Assembly (2)
Ball Eject Assembly (2)
Plfd. Slide Mechanism Assy., R.
Jet Bumper Coil Assembly (3)
Disappearing Post Assembly
Magnet Bracket Assembly
BottomTrough Assembly
Diverter Assembly
Plfd. Slide Mechanism Assy., L.
7-Lamp PCB Assembly
Vanishing Magnet Assembly
a-Lamp
PCB Assembly
5-Lamp PCB Assembly
Flipper Assembly, Right
8-Lamp PCB Assembly
7-Switch Opto PCB Assy.
Spike Assembly
3-Lamp Board
7-Lamp PCB Assembly
Flipper Assembly, Left
Support Bracket (2)
NOTE:
* Item located on
top of playfield.
2-34
Underside of playfield, viewed in raised position.
