Upper Playfield Parts
Item Part
Description
Item Part
Description
No.
No.
No.
No.
1 A-17730-3
Ball Shooter
wI
Siiver Knob
30 A-20638
Genie Double Target
23-6327
Ball Shooter Rubber Tip
31 A-20642
Loop Post Diverter
20-9927-1
Siiver Knob with Shaft
A-16636
Diverter Plunger Assembly
2 A-20842
Shooter Lane Switch & Bracket
32 A-20644
Vanishing Magnet
01-14004
Shooter Switch Bracket
04-10373
Magnet Pole Piece
3 20-9691
Level
20-10197
Coii Magnet & Brake-small hole
03-8633
Mount
33 A-18017-6
Yellow Standup Mini Target
4 A-14876-R-3
Flipper Coii Assembly
34 A-18530-6
Yellow Standup Target
20-10110-5
Flipper Shaft & White Bat
35 A-20810
Magnet Wire Ramp
5 A-20903
Rollover Button Assembly
36 B-9362-L-3
Coii & Bracket Assembly
A-16443
Switch & Diode Assembly
37 A-20628
Magnet Ramp
03-9103.1
Rollover Button
A-20879
Bed of Naiis
A-17806
Socket & Bulb
01-14268
End Ramp Guard
6 A-20878-1
Flipper Guide-Right
03-9255-3
Spacer #8 x .541
03-9216-18
Violet Flipper Return
38 A-20846-9
Red Standup Target
03-9255-3
Spacer #8 x .541
39 A-20499-9
Red Standup Target
7 A-20694
Guide Assembly
40 A-20695
Bracket & Opto Assembly
8 B-9362-L-3
Coil & Bracket Assembly
41 A-20693
Spike Assembly
9 A-20877-1
Scimitar Plastic
A-16909
Photo Transistor PCB Assembly
10 A-20627
Skill Ramp
02-5248
Spike Assembly
01-14268
End Ramp Guard
04-10333.1
Spike Plate Sub-assembly
01-14267.1
Skill Ramp Guard
42 B-9362-L-3
Coil & Bracket Assembly
11 A-20693
Spike Assembly
43 A-20878-2
Flipper Guide-Left
A-16909
Photo Transistor PCB Assembly
03-9216-18
Violet Flipper Return
02-5248
Spike Post
03-9255-3
Spacer #8 x .541
04-10333.1
Spike Plate Sub-assembly
44 A-20903
Rollover Button Assembly
12 A-20695-1
Bracket & Opto Assembly
A-16443
Switch & Diode Assembly
13 04-10337
Welded Sword Assembly
03-9103.1
Rollover Button
14 A-18530-6
Yellow Standup Target
A-17806
Socket & Bulb
15 A-18017-6
Yellow Standup Mini Target
45 A-15849-L-2
Flipper Coil Assembly
16 A-20691
Loop Sub-Assembly
20-10110-5
Flipper Shaft wI White Bat
5647-12693-13
Switch
46 A-13204-50047
Screened Bottom Arch
5070-09054-00
1N4004 Diode
47 12-7210
Rebound Wires
17 A-16434-2
Kicker Assembly
48 12-7315
Wire Ball Guide #7
18 A-20636
Spinning Lamp Assembly
49 12-7316
Wire Ball Guide #8
A-17826
Socket & Bulb
50 12-7317
Wire Ball Guide #9
01-14157
Actuator Bracket
51 12-7318
Wire Ball Guide #10
19 A-20692
Skill Shot Assembly
52 12-7319
Wire Ball Guide #11
SW-1A-202-15
Stationary Target Assembly
53 12-7326
Wire Ball Guide #12
A-17826
Socket & Bulb
54 12-7340
Wire Ball Guide
03-8063-2
Green Bulb Sleeve
55 01-14148
Ball Guide #1
20 A-20499-9
Red Stand up Target
56 01-14221
Ball Guide #14
21 B-9362-L-3
Coil & Bracket Assembly
57 01-14222
Ball Guide #15
22 A-20846-9
Red Standup Target
58 01-14223
Ball Guide #16
23 A-20626
Swirl Ramp
59 04-10297
Ball Guide #2
01-14266
Ramp Flap
60 04-10300
Ball Guide #5
A-20847
Ball Gate
61 04-10301
Ball Guide #6
03-8365-13
Post #8 -Clear
A-20811
Ramp Guard
A-20914
Plunger & Ball Guide Assembly
Not Shown:
24 A-18530-6
Yellow Standup Target
03-9488-1
*Full Playfield Mylar
25 A-20643
Ball Guide Diverter Assembly
02-5235
Diverter Shaft
03-9488-2
Jet Bumper Area Mylar
01-14163
Diverter Ball Guide
03-9488-3
Drop Area Mylar
(2)
01-14162
Diverter Flap
03-9488-4
Drop Area Mylar
(2)
26 B-9414-7
Jet Bumper Assembly
12-7210
Rebound Wires
B-12030-2
Switch Assembly
20-6500
**Steel
Balls
(6)
A-9415-2
Coil Assembly
3H357-50047
Backglass Translight
27 A-17932-2
Disappearing Post Assembly
28 A-20798
Back Panel
36-50047
Screened Hardcoat
Playfield
03-8171-26
Green Twist Lock Mini Dome
03-8171-16
Yellow Twist Lock Mini Dome
*The
Tales of the Arabian Nights
hardcoat
playfield does
29 A-20839
Magnet Diverter Unit
not require a full
mylar.
However,
mylars can be
20-10179
Coii Magnet & Brake-large hole
purchased through your local Williams Distributor.
12-7331
Magnet Wire
01-14262
Diverter Magnet Mounting Bracket
**There are four ball-in-play balls and two captive balls.
2-32
