tOR PINBALL
84•.,1855-COOO
4~C146
CRQSS REFERENCE LIST
DESCRIPTION
QTY. DESIGNATION NO.
PART NOS.
I
1
18 PF 50V AX CER.
C32
0365-00800-0026
100 PF 50Y AX CER.
4 C33~C36
0360-00800-0046
150,PF 50V AX CER.
1 C23
0360-00800-0053
270 PF 50V AX CER.
2 C24,C29
0307-00800-0009
470 PF SOY AX CER.
2 C26,C37
0307-00800-0008
.003 UF SOV AX CER.
1 C27
0360-00800~0056
.01 UF SOY AX CER.
13 C5,C7,C31,CP1-CP10
0360-00800-0005
• OS,
UF CER.
1 C15
0360-00800-0006
.1 UF 50V AX CER.
4 C13,C17,C38,C39
0360-00800-0058
.2l
UF SOV AX CER.
2 C10,C11
0360-00800-0057
1 Uf ,20V TANT.
3 C16,C25,C28
0986-00800-1400
4.7 UF 25Y TANT.
2 C4,C6
0360-00800-0008
6.Sl
UF 25V TANT.
1 C8
0360-00800~0048
10 ~F 20Y TANT.
1 C2
0986-00800-0700
47 ~F 16V AX ELEC.
1 C30
0360-00800-0042
470LUF 6V
AX
ELEC •
1 C14
0360-00800-0021
100~OUF 16Y
AX
ELEC.
1 C12
0360-00800-0044
4700 UF 25V
AX
ELEC.
1 C3
0360-00800-0023
i
1
OHM
1/4W 5% CRBN.
1 R19
100E-00005-0002
2.~ OHM 1/4W 5% CRBN. 1 R21
100E-00005-0003
68
iPHM 1/4W 5% CRBN.
1 R36
100E-00005-0029
82
toHt~
1/4W 5% CRBN.
1
R7
100E-00005-0031
lO~ OHM 1/4W 5% CRBN. 2 R8,R49
100E-00005-0033
lSq
OHM 1/4W 5% CRBN. 1 RSO
100E-00005-0037
18~ OHM 1/4W 5% CRBN. 1 R37
100E-00005-0039
22 BHM 1/4W 5% CRBN. 1 R22
100E-00005-0041
430 OHM 1/4W 5% CRBN. 1 R20
100E-00005-0050
91d
OHM 1/4W 5% CRBN. 1 R15
100E-00005-0059
1K !OHM 1/4W 5% CRBN.
2 R1,R60
100E-00005-0061
2.JK OHM 1/4W 5% CRBN. 3 R2, R3,R61
100E-00005-0071
3.3K OHM 1/4W 5% CRBN. 1 R51
100E-00005-0074
4.7K OHM 1j4W 5% CRBN. 8 R24,R4l-R47
100E-00005-0079
5.1K OHM 1/4W 5% CRBN. 1 R26
100E-00005-0080
S.6K OHM 1/4W 5% CRBN. 1 R14
100E-00005-0082
7.5K OHM 1/4W 5% CRBN. 1 R4
100E-00005-0085
9.1K OHM 1/4W 5% CRBN. 1 R6
100E-00005-0087
lOK OHM 1/4W 5% CRBN. 7 R10,R11,R53-R57
100E-00005-0088
l8K OHM 1/4W 5% CRBN. 1 R32
100E-00005-0093
33K OHM 1/4W 5% CRBN.
2
R31,R33
100E-00005-0100
39K OHM 1/4W 5% CRBN. 1 R5
100E-00005-0102
47K OHM 1/4W 5% CRBN.
3
R9,R39,R48
100E-00005-0104
62K OHM 1/4W 5% CRBN. 2 R13,R35
100E-00005-0107
75K OHM 1/4W 5% CRBN. 1 R38
100E-00005-0110
82K OHM 1/4W 5% CRBN. '2 R12 ,R29
100E-00005-0112
lOOK OHM 1/4W 5% CRBN. 1 R52
100E-00005-01lS
l20K OHM 1/4W 5% CRBN. 1 R34
100E-00005-0118
l50K OHM 1/4W 5% CRBN. 2 R28,R30
100E-00005-0120
200K OHM 1/4W 5% CRBN.
1
R40
100E-00005-0123
