Lower Playfield Parts
Hem
Part Number
Description
1
01-14003-2
Hanger Bracket - Left
2
A-23001-L-3
Flipper Assembly - Left
23-6519-4
Flipper Ring
20-10110-6
Flipper Bat w/Shaft (Yellow)
3
01-15201.1
Playfield Side Rail
4
A-22207-7
Coil
&
Bracket Assembly - Left
A-17811
Kicker Assembly
10-128
Kicker Spring
5
A-23173
21
Lamp PCB Assembly
6
A-23162
Light Tunnel Assembly
7
A-20246
10 Opto PCB Assembly w/Brackets
8
A-23177
3 Lamp PCB Assembly - Left
9
A-23176
4 Lamp PCB Assembly
10
A-23174
12
Lamp PCB Assembly
11
A-21829-1
Eject Assembly
12
A-23175
8
Lamp PCB Assembly
13
A-23293
1-Bank Drop target Assembly
14
A-23031
Short Opto Assembly
15
A-18008-2
Rollover Button Assembly
01-13204
Rollover button Spacer
16
04-12608.1-1
Playfield Slide Foot - Right
17
A-15646
24 Opto PCB Assembly
18
01-15125.4
Playfield Cable Bracket
19
01-15133.2
Playfield Support Bracket
20
A-23170
Ball Popper Assembly
21
A-2301 0
Bumper Target Coil Assembly
A-23009
Bumper Target Assembly
03-9998
Bumper target Bushing
22
04-12608.1-2
Playfield Slide Foot - Left
23
A-23032
Long Opto Assembly
24
A-22205-4
Jet Coil
&
Bracket Assembly
8-12030-2
Jet Bumper Leaf Switch Assembly
8-9414-8
Jet Bumper Assembly
25
A-23407
1-Bank Drop target Assembly
26
A-23178
3 Lamp PCB Assembly - Right
27
20-10197
Coil Magnet w/Bracket
28
A-22206-7
Coil
&
Bracket Assembly - Right
A-17811
Kicker Assembly
10-128
Kicker Spring
29
A-23001-R-3
Flipper Assembly - Right
23-6519-4
Flipper Ring
20-10110-6
Flipper Bat
w/Shaft
(yellow)
30
A-19963-4
Ball Trough Assembly
31
01-14003-1
Hanger Bracket - Right
Playfield Cables (Not Shown)
Part Number
Description
H-23180
Playfield Switch Cable
H-23181-1.1
Playfield Lamp A Cable
H-23181-2.1
Playfield Lamp B Cable
H-23182.1
Playfield Solenoid Cable
H-23183.1
Playfield Opto Cable
H-23186
24" Opto Cable
2-37
