CoIn
Door Intetface
BoatrJ
Continued •••
J8-1 YEL-VIO Lamp Column 1
J8-2 YEL-RED Lamp Column 2
J8-3 YEL-ORG Lamp Column 3
J8-4 BRN-BLK Lamp Row 1
J8-5 BRN-RED Lamp Row 2
J8-6 BRN-ORG Lamp Row 3
J8-7 BRN-YEL Lamp Row 4
J8-8 GRY-GRN Ticket Notch
J8-9 GRY-BLU Ticket Low
J8-10 GRY-YEL +12V
J8-11 GRN-BRN Switch Column 1
J8-12 GRN-RED Switch Column 2
J8-13 GRN-QRG Switch Column 3
J8-14 WHT-BRN Switch Row 1
J8-15 WHT-RED Switch Row 2
J8-16 WHT-ORG Switch Row 3
J8-17 WHT-YEL Switch Row 4
J8-18 Key
J8-19 WHT
Ticket Motor
J8-20 BLK
Ground
J9 Not Used
J10-1 N/e
J10-2 YEL-RED Lamp Column 2
J10-3 YEL-BRN Lamp Column 3
J10-4 Key
J10-5 N/e
J10-6 N/e
J10-7 N/e
J10-8 N/e
J10-9 N/e
J10-10 BRN-ORG Lamp 13
J10-11 ORG-BRN Lamp 23
J10-12 N/e
J10-13 N/e
J10-14 N/e
J10-15 N/e
3-25
