AS-2S18-21 DISPLAY DRIVER MODULE
A1: DISPLAY DRIVER MODULE
COMPONENT PARTS LIST
REFERENCE
BALLY
ITEM
OTY.
DESIGNATION
PART
#
DESCRIPTION
1
1
P-2948-296
P.C. Board, M-645-392
3
7
R1,R3,R5,R7,R9,R11,R34
E-105-226
Resistor, 100K Q
4
13
R14,R16,R18,R20,R22,
E-105-227
Resistor, 300K Q
R24,R26, R35,R36, R37,
R38,R39,R40
5
6
R43, R44, R45, R46, R47,
E-105-228
Resistor, 9.1 K Q
R48
6
7
R13, R15, R17, R19, R21,
E-105-229
Resistor, 1.5K Q
R23,R25
7
7
R27, R28, R29, R30, R31,
E-105-230
Resistor, 1K Q
R32,R33
8
R41
E-105-231
Resistor, 39K Q
9
R42
E-105-271
Resistor, 240K Q
10
11
1
C2
E-586-65
Capacitor, .01 MFD, 500V
13
6
07,08,09,010,011,012
E-S8S-32
Transistor (2NS401)
14
13
01,02,03,04,
OS, 06,
E-S8S-33
Transistor (MPS-A42)
013,014, 01S, 016, 017,
018,019
16
VR1
E-598-7
Zener Diode, 110V
17
U1
E-620-38
I.C. Decoder
18
19
2
J1
E-715-34
10 Pin Wafer Pin Connector
21
1
DS1
E-680
Digital Display Panel
22
2
M-1836
Hi-Lo Screw,
W/H
23
1
P-2399
Display Mounting"(Top)
24
1
P-2399-1
Display Mounting (Bottom)
26
6
R2,R4,R6,R8,R10,R12
E-10S·-281
Resistor, 2.2K 0
27
6
R49, RSO,R51, RS2,RS3,
E-10S-242
Resistor, 20K 0
RS4
28 As
Wire Jumper
Req'd
29
1
C1
E-586-85
Capacitor, .01 MFD, 25V
NOTE:
INTERCHANGEABLE WITH AS-2518-15
24
