SQUAWK
&
TALK MODULE
AS 2518-616
COMPONENTS PARTS LIST
REFERENCE
BALLY
ITEM QTY.
DESIGNATION
DESCRIPTION
PART
#
26
1 R37
Resistor, Y4W,5%,30K
E-l05-245
27
5 Ri2,36,57,58,81
Resistor,
V4W,
5%, 1K
E-l05-230
28
1 R51
Resistor,
V4W,
5%, 750K
E-105-344
29
1 R52
Resistor,
V4W,
5%, 9.1K
E-105-228
30
2 R9,16
Resistor,
V4W,
5%, 130K
E-l05-203
31
i
R11
Resistor,
V4W,
5%, 150K
E-105-248
{
32
1
R15
Resistor, V4W,5%, 220K
E-105-i6i
33
1
R14
Resistor, V4W,5%, 1.8K
E-105-346
34
4 Ri7,18,39,40
Resistor,
V4W,
5%, 910K
E-105-347
35
1 Ri
Resistor,
V4W,
5%, 27K
E-i05-243
36
1 R68
Resistor,
V4W,
5%, 510 J.1
E-l05-311
37
1 R34
Resistor,
V4W,
5%, 2.2 J.1
E-105-211
38
3 R31, 88, 89
Resistor,
V4W,
5%, 220 J.1
E-105-303
39
1
R79
Resistor, %W, 5%, 7.5K
E-105-345
40
1
R35
Resistor,.V4W, 5%, 1 J.1
E-105-196
.~
41
1 R83
Resistor,
V4W,
5%, 11K
E-i05-360
42
1 R7
Resistor,
V4W,
5%, 8.2K
E-105-223
43
14 C2,5-8, 10, 11, 17; 18,44,47-50 Capacitor, Ceramic, .01 /LF,25V
E-586-85
44
2 C23,35
Capacitor, Ceramic, .47/LF, 16V
E-586-130
,[
45
4 R84-87
Resistor,
V4W,
5%., 2.2K
E-l05-287
46
1 R6
Resistor,
V4W,
470J.1
E-105-342
47
7 CI9,24,25,28,31,34,42
Capacitor, Electrolytic, 1/LF,25V
E-586-90
48
10 CI2,13,26,30,33,39,40,41,
7
45,46
Capacitor, Ceramic, .1/LF, 25V
E-586-89
t
49
2 C9,20
Capacitor, Ceramic, 470pF, 50V
E-586-83
50
1 C32
Capacitor, Ceramic, 68pF
E-586-120
51
1 C21
Capacitor, Ceramic, 100pF
E-586-68
52
1 C15
Capacitor, Electrolytic, 10JLF,16V E-586-135
53
2 C16,22
Capacitor, Tantalum, 4.7/LF, 25V
E-586-73
54
1 C27
Capacitor, Electrolytic, 1000/LF, 16V E-586-i36
55
1 C29
Capacitor, Electrolytic, 470/LF, .6V E-586-124
r
56
2 C3,4
Capacitor, Ceramic, 27pF
E-586-121
57
1 C14
Capacitor, Electrolytic, 4700/LF, ..25V E-586-123
58
2 C37,38
Capacitor, Electrolytic, 330/LF, 50V E-586-147
59
1 C51
Capacitor, Monolythic, 10pF
E-586-150
/ .
60
1 J1
18 Pin Wafer Connector (156)
E-736-18
'\
61
1 J2
10 Pin Wafer Connector(156)
E-736-10
i
62
1 Used with VR1
Heatsink, 6053B
E-682-11
63
1 Used with U18
Heatsink, 6030B
E-682-8
64
12
Test Points
P-5399
65
1 SW.1
PC.B. Switch
E-658-1
66
3 CR7, 8,10
Diode (IN4004)
E-587-15
67
5 CR1, 5, 6, 9, 11
Diode (IN4148)
E-587-14
}
68
1
Yl
Crystal,3.579
E-744-5
69
1 LED1
LED
E-679
\
70
3 01-2,5
Transistor, 2N3904
E-585-31
71
1 Used with U10
Socket I.C. i 6 Pin
E-712-16
72
3 CR2-4
Diode, 3A, 50V. min.
E-587-24
1
73
1 Ul
6808 or 6802 (SEE NOTE 1)
'.
Microprocessor
E-620-125
or
128
74
3 Used with Ul, 7, 11
Socket, I.C. 40 Pin
E-712-1
75
3 Used with U8, 9, 12
Socket, I.C. 28 Pin
E-712-28
76
3 Used with Ui 8, VRI
Screw
LSPR-00632-1106
77
3 Used with U18, VR1
Nut
Nc00632-2112
78
79
J3
Header, 7 Pin
E-766-7
80
2 C36,43
Capacitor, 2/LF, 25V
E-586-63
81
2 R69,70
Pot.1K
E-599-16
82
1 C1
Capacitor, Electrolytic, 47/LF
E-586-148
83
2 R28,54
Resistor, 82K
E-105-341
84
AR Used with Ui 8, VR1
Thermal Compound
M-1834
85
2 03,4
Transistor, 2N4403
E-585-23
86
2 R82,48
Resistor, 1f4W,5%, 2.4K
E-l05-312
JUMPERS-SEE NOTES
