GAME #1262 SPECTRUM
SOLENOID IDENTIFICATION NUMBER
Self
Self
Test
#
SOLENOID IDENTIFICATION
Test
#
SOLENOID IDENTIFICATION
01 KNOCKER
08 GREEN DROP TARGET RESET
02 OUTHOLE KICKER
09 YELLOW DROP TARGET RESET
03_ LEFT SIDE MIDDLE SAUCER
10 RED DROP TARGET RESET
04 TOP SAUCER KICK TO LEFT
11 LEFT SIDE BOTTOM SAUCER
05 TOP SAUCER KICK TO RIGHT
12 RIGHT SIDE BOTTOM SAUCER
06 RIGHT SIDE MIDDLE SAUCER
13 K1 RELAY (FLIPPER ENABLE)
07 BLUE DROP TARGET RESET
14 COIN LOCKOUT DOOR
Switch
Switch
Self
Self
Test
#
DESCRIPTION
Test
#
DESCRIPTION
,01 RIGHT FLIPPER BUTTON
25 LEFT SIDE LANE UPPER (3)
02 LEFT FLIPPER BUTTON
26 LEFT SPINNER
03
27 #1 LEFT GREEN ROLLOVER BUTTON
(
04
28 #2 GREEN ROLLOVER BUTTON
05
29 #3 GREEN ROLLOVER'BUTTON
06 CREDIT BUTTON
J
30 #4 RIGHT GREEN ROLLOVER BUTTON
07 TOP SAUCER
31 RIGHT SPINNER
08. OUTHOLE KICKER
32 RIGHT SIDE LANE UPPER (3)
09 COIN 111 (RIGHT)
33 LEFT SPINNER LANE ROLLOVER
.BUTTONS (2)
10 COIN I (LEFT)
34 GREEN DROP TARGET (LEFT)
11 ' COIN II (MIDDLE)
35 . GREEN DROP TARGET (CENTER)
12
36 .GREEN DROP TARGET (RIGHT)
13
37 YELLOW DROP TARGET (LEFT)
14
36 YELLOW DROP TARGET (CENTER)
15 TILT (3)
39 YELLOW DROP TARGET (RIGHT)
'16 SLAM (2)
40 RIGHT SPINNER LANE RO~LOVER
BUTTON (2)
17 LEFT SLAM BOTTOM SAUCER
41 LEFT SIDE MIDDLE SAUCER
"18 LEFT SIDE LANE BEFORE
42 BLUE DROP TARGET (LEFT)
BOTTOM SAUCER
19 TOP LEFT SIDE R.O. BUTTON (3)
43 BLUE DROP TARGET (CENTER)
(
20 LEFTOUTLANE
44 BLUE DROP TARGET (RIGHT)
21 TOP RIGHT SiDE ROLLOVER BUTTON (3)
45 RED DROP TARGET (LEFT)
22 RIGHT OUTLANE
46 RED DROP TARGET (CENTER)
23 RIGHT SIDE LANE BEFORE
.47 RED DROP TARGET (RIGHT)
BOTTOM SAUCER
24 RIGHT SIDE BOTTOM SAUCER
48 RIGHT SIDE MIDDLE SAUCER
