XI. PARTS LIST
#1262 SPECTRUM
MISCELLANEOUS
PART NUMBER
Transformer (Domestic or Export)
E-122-142
Bulbs,.#555
E-125-73
Fuse, 1Amp. 3 AG Slow Blow (Playfield Solenoid Protection)
E-133-44
ASSEMBLY COILS
Coin Lockout
FO-36-7000
Flipper (2)
,
AQ-25-500/
34-4500
Knocker
AR-26-1200
Drop Target Reset (4)
NO-26-1900
Top Saucer Kick To Left & Right
"
AO-29-2100
Left & Right Middle Saucer
AO-29-1700
Left & Right Bottom Saucer
AO-28-1700
Outhole Kicker
AO-27-1300
PLAYFIELD
PARTS
See Figure II
MODULES
Lamp Driver A5 (2 used)
AS-2518-23
Display Driver A1 (1 used)
AS-2518-21
Display Driver A1 (4 used)
AS-2518-58
Solenoid Drive/voltage Regulator A3
AS-2518-22
MPU A4
'"
AS-2962-33
Transformer & Rectifier A2
AS-2877-6
Rectifier Board (Part of A2)
AS-2518-54
Squawk & Talk
AS-3107-10
Auxiliary Driver (SCR Lamp Flasher)
AS-2518-67
Aux. Driver (G.I. Flasher) (3 used)
,
;
AS-2518-68
REPAIRS PROCEDURES/AIDS
Module & Component Replacement
F.O.560-1
AID (Assistance in Diagnostics)
Kit, used with F.O.560-1
KIT #485-1
MODULE
COMPONENTS
SEE MODULE PARTS LIST
MODULE
COMPONENT STARTER KITS
(Each kit contains an assortment of the most needed electronic parts for use in Module repair.)
KIT #558- For Rectifier Board (Part of A2)
KIT #503-For MPU Board A4 (less Memory U1-U6)
KIT #492- For Solenoid Driver/voltage Regulator A3
KIT #493- For Display Driver A1
KIT #494- For Lamp Driver A5
