A-15849-L-2
Flipper Assembly
Hem Part Number
Description
Item Part Number
Description
1 B-13104-L
Flipper Base Assembly. Left
18
A-15848-L
Crank Link Assembfy. Left
2
SW-1A-194
Switch Assembly
a)
A-170SQ.L
Flipper Crank Assembly. Left
3 4701-00002-00
Lock Washer *6 Split
b) A-'SS47
Flipper Link Assembly
4 4105-01019·10
Sh. Metal Screw,
.5
x
518"
c)
02-4676
Link Spacer Bushing
5
4008-01079-05
Mach. Screw. 8-32 x 5116-
d) 4010-01086-14
Cap Screw. 10-32 x
7/8"
6
4701-00003-00
Lock Washer #8 Split
e}
4700-00023-00
Flat Washer.
5/8
x 13164 x 16ga.
7 01-9375
Switch Mounting Bracket
f)
4701 -00004-00 Lock Washer #10 Split
8
20-6516
Speednut. Tinnerman
g) 4410-01132-00
Nut 10-32 ESN
9
4010-01 066-06 Cap Screw, 10-32 x 3/8"
19
23-6577
Bumper Plug.
518-
10 4701-Q0004-00
Lock Washer ., 0 Split
20 03-7568
Ripper Bushing
11 A-12390
Flipper Stop Assembly
21
03-7066-5
CoUTubing
12
FL-"629
Ripper COil. Blue
13 01-7695-1
Solenoid Bracket
Associated Parts:
14 4006-01017-04
Mach. Screw. 6-32 x
'/4"
(Not Shown)
15
10-364
Spring
16 4006-01005-06
Mach. Screw, 6-32 x
3/S"
21
23-6695
Ripper Ring
'7 4406-0111 7-00 Nut 6-32 Hex.
22 20-10343
Flipper
&
Shaft
2-19
