Page 62 - Scared Stiff

FUSE LIST
-'.J'~ .1128 J!27
I~.•... :;r:::::-:"ej I:..• :j
s
§
o
o
§O
og
POWER DRIVER BOARD
Loc.
F101
F102
F103
F104
F105
F106
F107
F108
F109
F110
F111
F112
F113
F114
F115
F116
F117
F118
Description
Regulated 12V
Solenoids #9 to #16
Solenoids #1-#8
Solenoids #25 to #28
+5V Logic
+ 18V Lamp Matrix
Flasher Secondary
Solenoid Secondary
Unregulated 12V
G.!. #5 White-Violet
G,I. #4 White-Green
G.!. #3 White-Yellow
G.!. #2 White-Orange
G.t. #1 White-Brown
+50V Flippers
+50V Flippers
+SOV Flippers
+50V Flippers
Part Number
5731-14531-00
5731-14530-00
5731-14530-00
5731-14530-00
5731-14530-00
5731-14046-00
5731-14530-00
5731-14529-00
5731-14530-00
5731-14530-00
5731-14530-00
5731-14530-00
5731-14530-00
5731-14530-00
5731-14530-00
5731-14530-00
5731-14530-00
5731-14530-00
1-51
Value
TO.63A,25Ov
T4.0A,250V
T4.0A,250V
T4.0A,250V
T4.0A,250V
T5.0A,250V
T4.0A,250V
T6.3A,250V
T4.0A,250V
T4.0A,250V
T4.0A,250V
T4.0A,250V
T4.0A,250V
T4.0A,250V
T4.0A,250V
T4.0A,250V
T4.0A,250V
T4.0A,250V
