T.17 Coffin Test
Advance to test T.17 and press the Enter Button.
The coffin diverter will open and the display will show the status of each of the coffin lockup
switches. If a ball is placed in the coffin diverter entrance the operator can verify the correct
function of each of the coffin device opto's. The coffin lid will then open and the ball will be
ejected from the coffin. (After 30 seconds with no activity, the coffin test will automatically close
the diverter and exit. )
T.18 Crate Test -
Advance to test T.1B and press the Enter Button.
The crate test display will appear, showing the status of the crate switches. Passing a ball over
the sensor in front of the crate will cause the crate to unlock for approximately 5 seconds. A ball
can then be thrown into the crate to verify the correct function of the crate entrance opto. The
ball will be ejected from the crate and the crate will lock.
T.19 Empty Balls Test
This test kicks out all balls loaded in troughs, lockups, poppers, and
kickouts until no balls remain in those locations.
Note: As the trough kicks out balls, they will stack up in the shooter groove, which may require
manual clearing in order to allow further balls to be kicked out.
1-18
