COIN DOOR INTERFACE BOARD
A-20580
1
12 1
7 1
11
1 0 0 0 0 0 0 0
*
0 0 0 0
II
0 0 0
*
0 0 0110 0 0 0 0 0 0 0
*
0 01
J3
J2
J1
Jl0
<;:
0
0
0
0
0
0
0
0
*
0
0
0
-
0
-
J5
10 0 0
*
0 0 0 0 0 0 0 0 01
1:'3
,
10 0 0 0 0 0 0 0 0 0 0 0 0
*
01
15
1
J1-1 Orange-Gray, Oed. Sw. Row 8 Form CPU J205-9
J1-2 Orange-Violet, Oed. Sw. Row 7 from CPU J205-8
J1-3 Orange-Blue, Oed. Sw. Row 6 from CPU J205-7
J1-4 Orange-Green, Oed. Sw. Row 5 from CPU J205-6
J1
w
5 Orange-Yellow, Oed. Sw. Row 4 from CPU J205-4
J1-6 Orange-Black, Oed. Sw. Row 3 from CPU J205-3
J1-7 Orange-Red, Oed. Sw. Row 2 from CPU J205-2
J1-8 Orange-Brown, Oed. Sw. Row 1 from CPU J205-1
J1-9 Key
J1-10 Black, Ground from CPU J205-10
J1-11 Orange-White, Sw. Enable from CPU J205-12
J2-1 Black, Ground from Power Driver Board J139-3
J2-2 Gray-Yellow, +12VAC from Power Driver Bd. J139-2
J2-3 White-Violet, GI6.8VAC from Power Driver J104-1
J2-4 Key
J2-5 Violet, GJ. from Power Driver Bd. J104-3
J2-6 Not Used
J2-7 Black-White from J139-5
J3-1 Green-Brown, Sw.
cei.
1 from CPU J212-1
J3-2 Green-Red, Sw. Col. 2 from CPU J212-2
J3-3 White-Brown, Sw. Row 1 from CPU J212-4
J3-4 White-Red, Sw. Row 2 from CPU J212-6
J3-5 White-Orange, Sw. Row 3 from CPU J212-7
J3-6 White-Yellow, Sw. Row 4 from CPU J212-8
J3- 7 Not Used
J3-8 Key
J3"9 Yellow-Gray, Lamp Col. 8 from Power Driver J122-3
J3-10 Red-Blue, Lamp Row 6 from Power Driver J125-7
J3-11 Red-Violet, Lamp Row 7 from Power Driver J125-8
J3-12 Red-Gray, Lamp Row 8 from Power Driver J125-9
J4 Not Used
J5-1 Violet, G.!. Return to Coin Door
J5-2 White-Violet, G.I. 6.8VAC to Coin Door
J5-3 Black, Ground to Coin Door
I
00*00000001
1
10
[J -
~
..,
en
[DO -
-., 0
o
o
II>
J6
J5-4 Not Used
J5-5 Orange-Red. Oed. Sw. Row 2 to Coin Door
J5-6 Not Used
J5-7 Orange-Green, Oed. Sw. Row 5 to Coin Door
J5-8 Orange-Blue, Oed. Sw. Row 6 to Coin Door
J5-9 Orange-Violet, Oed. Sw. Row 7 to Coin Door
J5-10 Key
J5-11 Orange-Gray, Oed. Sw. Row 8 to Coin Door
J5-12 Green-Red, Sw. Col. 2 to Coin Door Slam Tilt
J5-13 White-Brown, Sw. Row 1 to Coin Door Slam Tilt
J6 Not Used
J7-1 Yellow-Gray. Lamp Col. 8 to Cabinet
J7 -2 Not Used
.
J7 -3 Not Used
J7-4 Red-Gray, Lamp Row 8 to Cabinet
J7-5 Key
J7-6 Green-BroWn, Sw. Col. 1 to Cabinet
J7-7 Not Used
J7-8 Not Used
J7 -9 Not Used
J7-10 Not Used
J7-11 White-Orange, Sw. Row 3 to Cabinet
J7-12 Not Used
J7-13 Not Used
J8-1 White, Sw. Row to Cabinet Slam Tilt
J8-2 Key
J8-3 Green, Sw. Col. to Cabinet Slam Tilt
J9-'
White-Yellow, Sw. Row 4 to Plumb Bob Tilt
J9-2 Key
J9-3 Green-Brown, Sw. Col. 1 to Plumb Bob Tilt
J9-4 White-Red, Sw. Row 2 to Interlock Sw.
J9-5 Green-Red, Sw. Col. 2 to Interlock Sw.
3-28
