SECTION THREE
GAME WIRING
AND SCHEMATICS
CONNECTOR & COMPONENT IDENTIFICATION
Each plug or jack receives a number that identifies the circuit board and the position on that board that it
connects to. J-deslgnations refer to a male connector. P·designations refer to a female connector.
For
example, J101 designates jack 1 of board 1 (a Power Driver board jack); P206 designates plug 6 of
board 2 (a CPU board plug). Identifying the specific pin number of a connector involves a hyphen, which
separates the pin number from the plug or jack designation. For example, J1 01·3 refers to pin 3 of jack 1
on board 1.
Other game components may also have similar numbers to clarify their locations or related circuits. For
example. F501 is a fuse on the Audio Video board.
Prefix numbers for WPC circuit boards are listed below.
Jl XX· Power Driver board jacks; F1XX . Power Driver board fuses.
J2XX • CPU Board (There are no fuses on the CPU board.)
J5XX and J6XX· Audio Video board (AV board) jacks; F5XX and F6XX • Audio Video board fuses.
Schematlcs for standard WPC backbox boards are found In the WPC Schematics Manual.
Playfleld, cabinet and all other backbox board schematics are found In this section.
3-1
