Upper Playfleld Parts
Item Part Number
Description
NOT SHOWN:
No.
2 20-10343
Flipper & Shaft
36-50048
t
Screened Playfield
3 03-9216-13
Flipper Retum Guide. Clear
01-12624
Lwr BoUom Arch Mtg. BMs. (2)
03-9613-2
Flipper Ban Guide Bone, Left
12-7210
Rebound Wire (2)
4 ,4,-20910
Kicker Assembly
A-21334-1
Playfield Plastic Assembly
23-6639
Boogie Man
A-21334-2
Playfl8ld Plastic Assembly
10-128
Spring
A·21334-3
Playfield Plastic Assembly
5
31-2568-2
Slingshot Bone. Left
A-21334-4
Playfield Plastic Assembly
7 ,0\-20717
Coffin Feed Popper Assembly
A-21334-5
Playfield Plastic Assembly
31-2589-1
Coffin Decal
A-21334-6
Playfield Plastic Assembly
31·2589-2
Coffin Decal
A-21334-7
Playfield Plastic Assembly
8 .1.·20783-7
Stationary Pop
Target
A-21334-8
Playfleld Plastic Assembly
,4,-20782
Pop Target Assembly
A·13204·5OO48 Bottom Arch Assembly
04-10510
Frog Assembly
20-6500-1
1/16"
Steel Ball (4)
9 01·14255
Ball Guide
03-9600-,
Full Playfield Mylar
10 01-14248
Ball Catcher Bracket
03-96()()"2
Playtield Mylar
11 ,0\-20769
Diverter Drive Assembly
03-9600-3
Playfield Mylar
04-10367.1
Dlverter Blade Assembly
03-9600-4
Playfield Mylar
12 01-14336
Ball Guide
03·9600-5
Playtleld Mylar
13 01·14254
Ball Guide
03-9600-6
Playfield Mylar
14 12-6466·9
Ball Guide Wire 2
Y.z"
15 12-7349
Ball Guide Wire
• Not Shown
16 12-7350
Ball Guide Wire
•• located Under Playfield
17 01·14253
Ball Guide
t
The
Scared
StI"hardcoat
playfield does not require a
18 03-8318-9
lite Hood, Red (4)
full mylar. However, mylars can be purchased through
19 A·12120
Ball Gate & Bracket Assembly
your local Bally Distributor.
20 ,0\·17797·1
Ball Gate Special Assy., Right
21 A-20835
Back Panel Assembly
22 01-14249
Ball Guide
23 12-7351
Ball Guide Wire
24 ,o\-9465-R
Ball Gate & Wire Assembly
25 01-14252
Ball Guide
26 01-14251
Ball Guide
27 B-9414-6
Jet Bumper Assembly. Black
03-9266-10
Jet Bumper Cap, Blue
03-9267-13
Jet Bumper Dome, Clear
28 A-21335
Crate Assembly
29
01·14256
Ball Guide
30 ,0\-21263
Switch Gate Assembly
31 ,0\-21032
Gate
&
Trap Door Assembly
32 01-14257
Ball Guide
33 A-21339
Ball Gale & Wire Assembly
34 01-14416
Ball Guide
35 31-2568-'
Slingshot Bone, Aight
36 A-20910
Kicker Assembly
10-128
Kicker Spring
23-6639
Boogie Man
37
03-9216-13
Flipper Aetum Guide, Clear
03-9613·1
Flipper Ball Guide Bone. Right
38 A·15802·P
level
39 01-10621
Strike Plate
40 ,0\·21022
Shooler Lane Auto Kicker ,o\ssy.
41 A-12120-1
Bali Gate & Wire Assembly
2-38
